MUNK Günzburger Steigtechnik 125133 Aluminium-coated, Aluminium Mobile scaffold Operating height (max.): 5.10 cm 4.30
EAN:
Part number:
Item no:
Highlights & Details
Munk FlexTower SG with preceding railings, platform height 3.10 m
- Can be mounted without any tools
Technical specifications
- Working height: 5100 mm
- Max. Standing height 3100 mm
- Roll diameter: 125 mm
- Frame width 2547 mm
- Frame length 3119 mm
- Platform length 1200 mm
- Frame height 4300 mm
- Platform height 3100 mm
- Max. Load 2 kN/m2
- Wide class W06
- Load class 3
- Product type
Mobile scaffold
- Working height range
5.1 cm - 6 cm
- Material
Aluminium-coated
Aluminium
- Weight
4.30
- No. of side arms
4
- Operating height (max.)
5.10 cm
- Platform width
600 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3401323 MUNK Günzburger Steigtechnik 125133 Aluminium-coated, Aluminium Mobile scaffold Operating height (max.): 5.10 cm 4.30
Description
Mobile frame made from sturdy aluminum round pipe with welded frame parts. In low-lying workplaces, the scaffold can also be mounted flexibly at lower installation heights. Thanks to the advance railing secured all around, can be set up and dismantled from level to level by one person (use up to two persons). Installation without any tools thanks to plug connectors and quick fasteners. Low weight of the individual parts for an easy handling. Space saving during transport and storage, since individual parts can be stored compactly and can be used as trolley. High flexibility and stability thanks to folding triangular arms with swivel base – Ideal also for wall-side construction or narrow gears. Four guide rollers Ø 125 mm with central load guide and spindles. Aluminium board boards and powder-coated railing frame with integrated knee strip for safety against crash. GS certification in accordance with DIN EN 1004. Load class/scaffold group 3: 2.0 kN/m²
