MUNK Günzburger Steigtechnik 50180 Aluminium Work platform Set-up requires tools Operating height (max.): 2.8 m
EAN:
Part number:
Item no:
Technical specifications
- External proof of inspection: 2228711KAU-014: 2017-11-06
- Upper tread width: 0.5 m.
- Platform height: 0.8 m
- Step/platform design: Aluminum fluted
- Product type
Work platform
- Working height range
2.1 m - 3 m
- Material
Aluminium
- Dim
(W x D) 0.64 m x 1 m
- No. of rungs/steps
4
- Operating height (max.)
2.8 m
- Design type
Fixed
- Features
Set-up requires tools
- Platform width
0.30 mm
- Platform depth
0.3 m
- Width
0.64 m
- Depth
1 m
- Load capacity (max.)
300 kg
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2270910 MUNK Günzburger Steigtechnik 50180 Aluminium Work platform Set-up requires tools Operating height (max.): 2.8 m
Certificate
Certificate 2270910 MUNK Günzburger Steigtechnik 50180 Aluminium Work platform Set-up requires tools Operating height (max.): 2.8 m
Description
Aluminum mounting platform particularly stable construction made of rectangular tube-beams Depth steps and large step area with riffing for a safe stand Non-slip plastic shoes optional spring-brake rollers for an easy procedure from place to place Easy assembly (dispatch takes place dismantled) Top step: 500 x 300 mm load max. 300 kg increased safety through one-sided handrail. This is supplied loose and can be screwed on easily (right-hand drill holes)
