Murrelektronik 85072 Rail mounted PSU (DIN) 28 V DC 24 A No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Fastening method: Screw fixing M4, 4 pieces in rectangle 60×197 mm
- Frequency: 50 Hz - 60 Hz
- Device protection: short-circuit and overload-proof
- LED display: LED (green) for output voltage
- Relative humidity: 5 % - 95 %, condensation not permitted
- Ripple: Max. 20 mV rms/RMS
- External backup fuse: Max. 3× 3 A
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
360 V AC
- Output voltage
24 V DC
- Inputs
1.2 A
- Input voltage
360 - 550 V
- Input voltage (max.)
550 V AC
- Max. output current
24 A
- Output current (max.) - rounded
24 A
- Output type (power supply units)
Adjustable
- Phases
3
- Output voltage (nominal)
28 V DC
- No. of outputs
1 x
- Dim
(L x W x H) 247 x 84 x 209 mm
- Output voltage (max.)
28 V DC
- Output voltage (min.)
24 V DC
- Operating temperature (max.)
+60 °C
- Operating temperature (min.)
0 °C
- Manufacturer part #
85072
- Content
1 pc(s)
- Width
84 mm
- Height
209 mm
- Length
247 mm
- Max. temperature
+60 °C
- Min. temperature
0 °C
- Type
85072
- Efficiency
90 %
