Murrelektronik 85349 Power supply unit 24 V 1 A Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product family: MEN
- Features: Low interference
- Suitable for mounting type: Key hole suspension
- CE 1
- Protection class: IP20
- UKCA 1
- Phases: 1;2
- Depth: 120
- Type of connection: Screw terminal
- Type: Transformer power supplies
- Width: 78
- Mains frequency: 50 ... 60 Hz
- Min. Operating temperature: -20
- Height: 64
- Max. Operating temperature: 60
- EMISSION: EN IEC 55011;IEC 61000-3-2
- CURus: 1
- Output voltage: 24 V … 24 V.
- Output voltage DC 24
- Characteristic: Slow-blow
- Safety measure: SELV
- Input voltage: 215 V … 245 V
- Operating current: 0 A … 1 A.
- Max. Operating current: 1
- Output circuit: VDR, Sieve capacitor, LED
- CULus 1
- Secondary fuse type: Fuse FKS
- Operating current min.: 0
- Max. Output current 0.4 A @ 230 VAC
- MATERIAL SHORT TEXT: MEN 1 230-400 +-15V/24 DC
- Derating 40
- Mounting dimension a: 47.5
- Residual ripple max. 5
- Mounting dimension b: 56
- Mounting dimension c: 4.8
- Input voltage 1 AC min.: 195.5
- Security External secondary side: 3
- Input voltage 1 AC max. 264.5
- Product standard: EN IEC 61558-2-6;IEC 62041 Category I.
- Input voltage 2 AC min.: 340
- Input voltage 2 AC max. 460
- Security 2 primary side external: 25 A @ 400 VAC
- RATED INPUT VOLTAGE AC: 230 V … 400 V
- NOMINAL CURRENT AC:0.25 A @ 230 V,0,145 A @ 400 V
- Nominal input voltage
230 V/AC
- Product type
Power supply unit
- Output voltage
24 V … 24 V
- Input voltage
215 V … 245 V
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Output type (power supply units)
Fixed voltage
- Phases
2
- Output voltage (nominal)
24 V
- Connection
Screw terminal
- Dim
(W x H x D) 78 x 64 x 120 mm
- Output voltage (max.)
24 V
- Output voltage (min.)
24 V
- Operating temperature (max.)
60 °C
- Operating temperature (min.)
-20 °C
- Manufacturer part #
85349
- Content
1 pc(s)
- PSU features
Regulated
- Width
78 mm
- Height
64 mm
- Max. temperature
60 °C
- Min. temperature
-20 °C
- Type
MEN 1 230-400 +-15V/24 DC
- Depth
120 mm
- Protection class
IP20
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3762783 Murrelektronik 85349 Power supply unit 24 V 1 A Content 1 pc(s)
Datasheet 3762783 Murrelektronik 85349 Power supply unit 24 V 1 A Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3762783 Murrelektronik 85349 Power supply unit 24 V 1 A Content 1 pc(s)
Description
MEN transformer power supply 1/2-phase, screened IN: 230/400+/-15VAC OUT: 24V/1ADC-MEN transformer power supply 1/2-phase, sieved-Murrelektronik GmbH
