Murrelektronik 85357 Power supply unit 24 V 7.5 A Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product family: MEN
- Features: Low interference
- Suitable for mounting type: Key hole suspension
- CE 1
- Protection class: IP20
- UKCA 1
- Phases: 1;2
- Depth: 150.5
- Type of connection: Screw terminal
- Type: Transformer power supplies
- Width: 105
- Mains frequency: 50 ... 60 Hz
- Min. Operating temperature: -20
- Height: 103
- Max. Operating temperature: 60
- EMISSION: EN IEC 55011;IEC 61000-3-2
- CURus: 1
- Output voltage: 24 V … 24 V.
- Output voltage DC 24
- Safety measure: SELV
- Input voltage: 215 V … 245 V
- Operating current: 5 A … 7.5 A.
- Max. Operating current: 7.5
- Output circuit: VDR, Sieve capacitor, LED
- CULus 1
- Secondary fuse type: Fuse FKS
- Operating current min.: 5
- Max. Output current 2 A @ 230 VAC
- MATERIAL SHORT TEXT: MEN 7.5-230-400 +-15V/24VDC
- Derating 40
- Mounting dimension a: 86.5
- Residual ripple max. 5
- Mounting dimension b: 80.5
- Mounting dimension c: 5.8
- Input voltage 1 AC min.: 195.5
- Security External secondary side: 15
- Input voltage 1 AC max. 264.5
- Product standard: EN IEC 61558-2-6;IEC 62041 Category I.
- Input voltage 2 AC min.: 340
- Input voltage 2 AC max. 460
- Security 2 primary side external: 1.25 A @ 400 VAC
- RATED INPUT VOLTAGE AC: 230 V … 400 V
- NOMINAL CURRENT AC:1.44 A @ 230 V,0.84 A @ 400 V
- Product type
Power supply unit
- Output voltage
24 V … 24 V
- Input voltage
215 V … 245 V
- Max. output current
7.5 A
- Output current (max.) - rounded
7.5 A
- Output type (power supply units)
Fixed voltage
- Phases
2
- Output voltage (nominal)
24 V
- Connection
Screw terminal
- Dim
(W x H x D) 105 x 103 x 150.5 mm
- Output voltage (max.)
24 V
- Output voltage (min.)
24 V
- Operating temperature (max.)
60 °C
- Operating temperature (min.)
-20 °C
- Manufacturer part #
85357
- Content
1 pc(s)
- Width
105 mm
- Height
103 mm
- Max. temperature
60 °C
- Min. temperature
-20 °C
- Type
MEN 7,5-230-400 +-15V/24VDC
- Depth
150.5 mm
- Protection class
IP20
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3762800 Murrelektronik 85357 Power supply unit 24 V 7.5 A Content 1 pc(s)
Datasheet 3762800 Murrelektronik 85357 Power supply unit 24 V 7.5 A Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3762800 Murrelektronik 85357 Power supply unit 24 V 7.5 A Content 1 pc(s)
Description
MEN 1/2-phase transformer, screened IN: 230/400+/-15VAC OUT: :24V/7.5ADC-MEN transformer 1/2-phase, sieved-Murrelektronik GmbH
