Murrelektronik 86044 Safety transformer 800 VA
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MET single-phase safety transformer
- 800 VA
Technical specifications
- Suitable for mounting type: Key hole suspension
- CE 1
- UKCA 1
- Depth: 160
- Ambient conditions: Up to 60° ambient temperature
- Type of connection: Screw terminal
- Width: 174
- Output 800 VA
- Mounting type: Screw fixing
- Mains frequency: 50 ... 60 Hz
- Min. Operating temperature: -20
- Height: 117
- Max. Operating temperature: 60
- Min. Storage temperature: -40
- Storage temperature max.: 80
- CURus: 1
- Output voltage 24 V
- Safety measure: SELV
- INPUT VOLTAGE 400 V;420 V;380 V
- Input voltage AC 400
- Input voltage AC min.: 380
- Input voltage AC max. 420
- Input current AC:2.15
- Material short text: MET 0800-400+-5%/24
- Switch-on current max.: 49.12
- Switching capacity AC max. 800
- Short circuit current 50.4
- Mounting dimension a: 92
- Mounting dimension b: 135
- Mounting dimension c: 7
- Length of hole: 11
- Diameter of bore: 7
- Output voltage AC 24
- Ambient temperature: -40 °C - 80 °C
- Input - output insulation test voltage: 4
- Product standard: EN IEC 61558-2-4;EN IEC 61558-2-6;IEC 62041 category 0
- DNV: 1
- Product type
Safety transformer
- Output voltage
24 V
800 VA
- Connection
Screw terminal
- Width
174 mm
- Height
117 mm
- Dim
(W x H x D) 174 x 117 x 160 mm
- Content
1 pc(s)
- Type
MET 0800-400+-5%/24
- Depth
160 mm
- Input voltage
400 V;420 V;380 V
- Max. temperature
60 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3762773 Murrelektronik 86044 Safety transformer 800 VA
Datasheet 3762773 Murrelektronik 86044 Safety transformer 800 VA
User & Safety Instructions
User & Safety Instructions 3762773 Murrelektronik 86044 Safety transformer 800 VA
Description
MET Single-phase safety transformer P: 800VA IN: 400VAC+/- 5% OUT: 24VAC-MET Single-phase safety transformer-Murrelektronik GmbH
