Murrelektronik 86183 Safety transformer 100 VA
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MTS single phase safety transformer
- 100 VA
Technical specifications
- Suitable for mounting type: Key hole suspension
- CE 1
- UKCA 1
- Depth: 93
- Ambient conditions: Up to 40° ambient temperature
- Type of connection: Screw terminal
- Width: 84
- Output 100 VA
- Mounting type: Screw fixing
- Mains frequency: 50 ... 60 Hz
- Min. Operating temperature: -20
- Height: 88
- Max. Operating temperature: 40
- Min. Storage temperature: -40
- Storage temperature max.: 80
- CURus: 1
- Connection type 1: Input
- Output voltage 24 V
- Connection type 2: Output
- INPUT VOLTAGE 460 V;230 V;400 V;420 V;500 V;208 V;480 V;440 V;380 V;525 V;550 V
- Material short text: MTS 0100-208...550/24
- Short circuit current at input voltage 1: 7.6
- Short circuit current at input voltage 2: 2.9
- Switching capacity AC max. 100
- Mounting dimension a: 64.5
- Mounting dimension b: 64
- Mounting dimension c: 4.8
- Length of hole: 8.4
- Diameter of bore: 4.8
- Output voltage AC 24
- Ambient temperature: -40 °C - 80 °C
- Input - output insulation test voltage: 6.3
- Switch-on current at input voltage 1:9.7
- Product standard: EN IEC 61558-2-4;EN IEC 61558-2-6;IEC 62041 category 0
- Switch-on current at input voltage 2:3.7
- DNV: 1
- RATED INPUT VOLTAGE AC: 208 V … 550 V
- NOMINAL CURRENT AC:0.57 A @ 208 V,0.21 A @ 550 V
- Product type
Safety transformer
- Output voltage
24 V
100 VA
- Connection
Screw terminal
- Width
84 mm
- Height
88 mm
- Dim
(W x H x D) 84 x 88 x 93 mm
- Content
1 pc(s)
- Type
MTS 0100-208...550/24
- Depth
93 mm
- Input voltage
460 V;230 V;400 V;420 V;500 V;208 V;480 V;440 V;380 V;525 V;550 V
- Max. temperature
40 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3762833 Murrelektronik 86183 Safety transformer 100 VA
Datasheet 3762833 Murrelektronik 86183 Safety transformer 100 VA
User & Safety Instructions
User & Safety Instructions 3762833 Murrelektronik 86183 Safety transformer 100 VA
Description
MTS Single phase safety transformer P: 100VA IN: 208...550VAC OUT: 24VAC For screw and mounting rail mounting MTS Single phase safety transformer-Murrelektronik GmbH
