Murrelektronik 86328 Safety transformer 1 x 230 V, 400 V 1 x 24 V AC 500 VA Piece
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 105.03 / piece)
€ 105.03
plus VAT.
Only 2 Piece(s) available
Highlights & Details
Single phase-safety transformer MST Series
- This text is machine translated.
Technical specifications
- Packaging type
Piece
- Product type
Safety transformer
- Output voltage
24 V AC
- No. of outputs
1 x
- No. of inputs
1 x
500 VA
- Input voltage
230 V
400 V
- Standards
Complies with EN 61558 · Contact protection as per EN 60529
- Connection
Spring-loaded terminal
- Width
135 mm
- Height
108 mm
- Length
133.6 mm
- Dim
(L x W x H) 133.6 x 135 x 108 mm
- Output voltage (number x voltage)
1 x 24 V AC
- Input voltage (number x voltage)
1 x 230 V, 400 V
- Frequency
50 - 60 Hz
- Weight
6.4500 kg
- Content
1 pc(s)
- Insulation class
T 40/B
- Mounting type
L-piece
DIN rail
- Protection class
IP20
- Type
MST 0500-230-400/24
- Max. ambient temperature
+40 °C
- Min. ambient temperature
-20 °C
500 VA
- Output voltage
24 V AC
- Input voltage
230/400 V AC
- Primary voltage
230/400 V AC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 710232 Murrelektronik 86328 Safety transformer 1 x 230 V, 400 V 1 x 24 V AC 500 VA Piece
User & Safety Instructions
User & Safety Instructions 710232 Murrelektronik 86328 Safety transformer 1 x 230 V, 400 V 1 x 24 V AC 500 VA Piece
Description
With key hole suspension.
