Murrelektronik 86378 Control transformer 500 VA
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MST single-phase control and isolating transformer
- 500 VA
Technical specifications
- Suitable for mounting type: Key hole suspension
- CE 1
- UKCA 1
- Depth: 132
- Ambient conditions: Up to 40° ambient temperature
- Type of connection: Screw terminal
- Width: 135
- Output 500 VA
- Mounting type: Screw fixing
- Mains frequency: 50 ... 60 Hz
- Min. Operating temperature: -20
- Height: 108
- Max. Operating temperature: 40
- Min. Storage temperature: -40
- Storage temperature max.: 80
- CURus: 1
- Connection type 1: Input
- Output voltage 230 V
- Connection type 2: Output
- Input voltage 230 V;400 V
- Material short text: MST 0500-230-400±15V/230
- Short circuit current at input voltage 1: 52
- Short circuit current at input voltage 2: 30
- Switching capacity AC max. 500
- Mounting dimension a: 87
- Mounting dimension b: 104
- Mounting dimension c: 5.8
- Output voltage AC 230
- Ambient temperature: -40 °C - 80 °C
- Input - output insulation test voltage: 5.8
- Input voltage 1 AC min.: 195.5
- Switch-on current at input voltage 1:25
- Input voltage 1 AC max. 264.5
- Product standard: EN IEC 61558-2-6;IEC 62041 Category 0
- Switch-on current at input voltage 2:15
- Input voltage 2 AC min.: 340
- Input voltage 2 AC max. 460
- DNV: 1
- RATED INPUT VOLTAGE AC: 230 V … 400 V
- NOMINAL CURRENT AC:2.4 A @ 230 V,1.4 A @ 400 V
- Product type
Control transformer
- Output voltage
230 V
500 VA
- Connection
Screw terminal
- Width
135 mm
- Height
108 mm
- Dim
(W x H x D) 135 x 108 x 132 mm
- Content
1 pc(s)
- Type
MST 0500-230-400±15V/230
- Depth
132 mm
- Input voltage
230 V;400 V
- Max. temperature
40 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3762779 Murrelektronik 86378 Control transformer 500 VA
Datasheet 3762779 Murrelektronik 86378 Control transformer 500 VA
User & Safety Instructions
User & Safety Instructions 3762779 Murrelektronik 86378 Control transformer 500 VA
Description
MST Single-phase control and isolating transformer P: 500VA IN: 230/400 +/- 15VAC OUT: 230VAC-MST Single-phase control and isolating transformer Murrelektronik GmbH
