Murrelektronik E-Stop 42 2NC M12(4) Kill button for emergency power-off 2.2 2 breakers 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Technical specifications
- CE 1
- Protection system: IP65
- UKCA 1
- Depth: 42
- Type: Emergency stop button
- Width: 124
- Min. Operating temperature: -25
- Height: 52
- Material contact: Ag Ni
- Max. Operating temperature: 70
- Min. Storage temperature: -25
- Storage temperature max.: 85
- Condition life: Load dependent;temperature dependent
- USAGE CATEGORY AC-15: 1.5 A @ 240 V
- CONNECTION TECHNOLOGY I/O M12
- USAGE CATEGORY DC-13: 2 A @ 24 V
- Number of pins: 4
- Mechanical life 0
- Material short text: E-Stop 42 2NC M12 (4)
- Mechanical life B10d: 250000
- Bounce duration max.: 10
- Electrical life: 0
- Switching current 2.2
- Lambda opener: 20
- TÜV SÜD FS: 1
- Ambient temperature: -25 °C to 85 °C
- Product type
Kill button
- Switch/button features
for emergency power-off
- Unlocking mechanism
Turn
- Print motif
EMERGENCY STOP
- Contact material
AgNi
- Contact type
2 breakers
- Connection
M12 plug
- Functions
latch
- Durability
0
- Width
124 mm
- Height
52 mm
- Switching current (max.)
2.2
- Min. temperature
-25 °C
- Max. temperature
70 °C
- Type
E-Stop 42 2NC M12(4)
- Content
1 pc(s)
- Dim
(W x H x D) 124 x 52 x 42 mm
- Depth
42 mm
- Number of pins
4
- Protection class
IP65
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3762743 Murrelektronik E-Stop 42 2NC M12(4) Kill button for emergency power-off 2.2 2 breakers 1 pc(s)
Datasheet 3762743 Murrelektronik E-Stop 42 2NC M12(4) Kill button for emergency power-off 2.2 2 breakers 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3762743 Murrelektronik E-Stop 42 2NC M12(4) Kill button for emergency power-off 2.2 2 breakers 1 pc(s)
Description
Emergency stop/emergency stop button with 2 forced open contacts in IP65 housing M12 connection, 4-pole Turn release left/right-emergency-off/emergency-stop button with 2 forced-opening Murrelektronik GmbH
