Buy My Wall H 25-1 L TV wall mount 81,3 cm (32") - 139,7 cm (55") Tiltable, Swivelling

Wall mount for television with pivoting arm, made of black metal, allows flexible adjustment of screen position.<br><br>Television wall bracket with a swivelling arm, crafted from black metal, enabling versatile positioning of the screen.

'Technical drawing of a TV wall mount, showing adjustable height and rotation angles, maximum load capacities and dimensions.'

1/2

Fast track dispatch on Tue, 6 Oct

1 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 25.20 / piece)

€ 25.20

plus VAT.

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

My Wall H 25-1 L TV wall mount

Holder type: Tiltable, Swivelling
Supports VESA standards up to
Suitable for displays sized (range): 81,3 cm (32") - 139,7 cm (55")
Load capacity (max.) 50 kg

Technical specifications

Product type: TV wall mount

Suitable for: 101,6 cm (40")
104,1 cm (41")
106,7 cm (42")
109,2 cm (43")
121,9 cm (48")
124,5 cm (49")
127,0 cm (50")
129,5 cm (51")
132,1 cm (52")
134,6 cm (53")
137,2 cm (54")
139,7 cm (55")
81,3 cm (32")
83,8 cm (33")
86,4 cm (34")
88,9 cm (35")
91,4 cm (36")
94,0 cm (37")
96,5 cm (38")
99,1 cm (39")
Show more

Suitable for: 81,3 cm (32") - 139,7 cm (55")

Holder type: Tiltable
Swivelling

Max. load capacity: 50 kg

: No

: 100 x 100 mm
100 x 200 mm
150 x 100 mm
200 x 100 mm
200 x 200 mm
200 x 300 mm
200 x 400 mm
300 x 100 mm
300 x 200 mm
300 x 300 mm
300 x 400 mm
400 x 200 mm
400 x 300 mm
400 x 400 mm
Show more

Rotation: 6°

Tilt range (bottom): -20°

Tilt range (top): +10°

Swivel range (left): 180°

Swivel range (right): 180°

Distance to wall (min.): 6 cm

Distance to wall (max.): 47.3 cm

Width: 4.8 cm

Height: 43 cm

Depth: 10 cm

Factory colour: Black

Material (details): Metal

Weight: 4300 g

Dim: (W x H x D) 4.8 x 43 x 10 cm

Compliance & Certifications

Certified by EU Garan

Variants(All information is without VAT, plus shipping costs)

Holder type

Suitable for

VESA standard

Max. load capacity

My Wall H 25-1 L TV wall mount 81,3 cm (32") - 139,7 cm (55") Tiltable, Swivelling

Item no:1537636

This article

TiltableSwivelling

81,3 cm (32") - 139,7 cm (55")

100 x 100 mm100 x 200 mm150 x 100 mm200 x 100 mm200 x 200 mm200 x 300 mm200 x 400 mm300 x 100 mm300 x 200 mm300 x 300 mm300 x 400 mm400 x 200 mm400 x 300 mm400 x 400 mm

50 kg

My Wall H 9-1 L TV wall mount 33,0 cm (13") - 76,2 cm (30") Rigid

Item no:1537627

Rigid

33,0 cm (13") - 76,2 cm (30")

75 x 75 mm100 x 100 mm

20 kg

My Wall H 9-1 SL TV wall mount 33,0 cm (13") - 76,2 cm (30") Rigid

Item no:1537628

Rigid

33,0 cm (13") - 76,2 cm (30")

75 x 75 mm100 x 100 mm

20 kg

My Wall HP 5-1 ASL TV wall mount 81,3 cm (32") - 139,7 cm (55") Rigid

Item no:1537632

Rigid

81,3 cm (32") - 139,7 cm (55")

100 x 100 mm100 x 200 mm150 x 100 mm200 x 100 mm200 x 200 mm200 x 300 mm200 x 400 mm300 x 100 mm300 x 200 mm300 x 300 mm300 x 400 mm400 x 200 mm400 x 300 mm400 x 400 mm

40 kg

My Wall HP 5-2 ASL TV wall mount 81,3 cm (32") - 177,8 cm (70") Rigid

Item no:1537633

Rigid

81,3 cm (32") - 177,8 cm (70")

100 x 100 mm100 x 200 mm150 x 100 mm200 x 100 mm200 x 200 mm200 x 300 mm200 x 400 mm300 x 100 mm300 x 200 mm300 x 300 mm300 x 400 mm400 x 200 mm400 x 300 mm400 x 400 mm

40 kg

My Wall H 25-2 L TV wall mount 94,0 cm (37") - 177,8 cm (70") Tiltable, Swivelling

Item no:1537637

TiltableSwivelling

94,0 cm (37") - 177,8 cm (70")

200 x 200 mm200 x 300 mm200 x 400 mm300 x 100 mm300 x 200 mm300 x 300 mm300 x 400 mm400 x 200 mm400 x 300 mm400 x 400 mm500 x 350 mm500 x 400 mm600 x 200 mm600 x 300 mm600 x 400 mm

50 kg

My Wall H 18-3 L TV wall mount 66,0 cm (26") - 152,4 cm (60") Tiltable, Swivelling

Item no:1537642

TiltableSwivelling

66,0 cm (26") - 152,4 cm (60")

100 x 100 mm100 x 200 mm150 x 100 mm200 x 100 mm200 x 300 mm200 x 400 mm300 x 100 mm300 x 200 mm300 x 300 mm300 x 400 mm400 x 200 mm400 x 300 mm400 x 400 mm

40 kg

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1537636 My Wall H 25-1 L TV wall mount 81,3 cm (32") - 139,7 cm (55") Tiltable, Swivelling

Warranty Terms

Warranty Terms 1537636 My Wall H 25-1 L TV wall mount 81,3 cm (32") - 139,7 cm (55") Tiltable, Swivelling

Description

Contortions and neck pain thanks to the fully movable wall holder is a thing of the past. You will find the ideal, reflection-free viewing angle tool-free swivelling, inclination and rotation of your monitor. The integrated cable management also takes care of order and clarity in your living room.

This text is machine translated.

Features

Double-articulated arm: side rotation 180°
Screen horizontal adaptable: +/- 3°,
With cable management,

Scope of delivery

Mount
Screw set
Installation manual.
