Buy Neotech Neotech 14 Condensate pump 11 l/h 22 m 230 V

A flow sensor with an arrow indicating direction, attached to tubing and a connector with wires, used for measuring fluid flow.

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Neotech 14 - V max.= 13.8l/h H max.=22 m

21 dB(A) noise level; larger flow; energy saving; automatic operation and alarm indication

Technical specifications

Nominal current max. 30 mA
Alarm contacts: Changer max. 10A 250V
Noise level 21 dB(A)

Product type: Condensate pump

Type: Mini condensation pump for air conditioning systems up to max. 15 kW

Operating voltage: 230 V

Max. delivery head: 22 m

Max. feed rate: 11 l/h

Pressure connection: 5mm

Max. cable length: 2 m

Weight: 1.1 kg

: IP20

Documents & Downloads

Datasheet

Datasheet 3733451 Neotech Neotech 14 Condensate pump 11 l/h 22 m 230 V

User & Safety Instructions

User & Safety Instructions 3733451 Neotech Neotech 14 Condensate pump 11 l/h 22 m 230 V

Description

Mini-Condensate pump for fully automatic conveyance of condensation from wall-mounted air-conditioning devices. The larger flow rate as well as the quick connection and interchangeability in case of service makes the Neotech 14 the best solution when it comes to disposing of the condensate from the air-conditioning system. The extra-large tank with level sensors is designed in such a way that the number of starts and stops is reduced and the running time is increased. This leads to reliability, less noise and a longer operating time. A simple plug connection The power supply and alarm signal simplifies installation, maintenance and service. The low noise level of the pumps allows installation anywhere. Pump dimensions 91 x 35 x 50 mm, collection tank dimensions 45 x 35 x 85 mm

This text is machine translated.
