NETGEAR GS105EP-100EUS GS105EP Network switch 5 ports 10 GBit/s PoE
EAN:
Part number:
Item no:
Datasheet (PDF)
NETGEAR GS105EP unmanaged gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) gray
Highlights & Details
- PoE+ support with a power of 63 W for powering devices
- Five Gigabit Ethernet ports for high-speed connections
- Functions like VLAN-support and IGMP-Snooping
- Fanless design for noiseless operation
- Web GUI management portal for configuration
Technical specifications
- Energy source AC / DC
- Product type
Network switch
- Transfer rate
10 GBit/s
- Working principle
Unmanaged switch
- IEEE 802.3af PoE
4
- 10/100/1000 Mbps ports
5 x
- Router features
PoE
- MAC addresses
2000
- Weight
390 g
- Width
158 mm
- Height
27 mm
- Depth
101 mm
- Type
GS105EP
- Factory colour
Grey
- Port
5 ports
- Material (details)
Metal
- Max. operating noise
0 dB
- Power consumption (ON)
4 W
- Transfer type
Corded
- UKCA
yes
- Operating temperature (T-T)
0 - 40 °C
- Power over Ethernet plus (PoE+) ports quantity
4
- Basic switching RJ-45 Ethernet ports quantity
5
- Total Power over Ethernet (PoE) budget
63 W
- Packet buffer memory
1.5 MB
- Number of multicast groups filtered
128
- Storage relative humidity (H-H)
0 - 95 %
- Password protection
yes
- Jumbo frames
9216
- Power over Ethernet (PoE) power per port
30 W
- Flow control support
yes
- Power over Ethernet (PoE)
yes
- Quality of Service (QoS) support
yes
- Port mirroring
yes
- Stackable
no
- Jumbo frames support
yes
- Multicast support
yes
- Rate limiting
yes
- Manual
yes
- Quick start guide
yes
- Mean time between failures (MTBF)
1164104 h
- Full duplex
yes
- MAC address table
2000 Eintragungen
- IGMP snooping
yes
- Operating altitude
0 - 3000 m
- Operating relative humidity (H-H)
0 - 90 %
- Storage temperature (T-T)
-20 - 70 °C
- Power consumption (max)
74.7 W
Documents & Downloads
Datasheet
Datasheet 3773448 NETGEAR GS105EP-100EUS GS105EP Network switch 5 ports 10 GBit/s PoE
User & Safety Instructions
User & Safety Instructions 3773448 NETGEAR GS105EP-100EUS GS105EP Network switch 5 ports 10 GBit/s PoE
Description
The NETGEAR Easy Smart GS105EP has been developed for network performance in a compact design. This switch has functions like VLAN-support, IGMP-Snooping and Quality of Service (QoS) that enable an efficient data management and prioritization of the bandwidth for applications. With its fan-less design and metal housing, it ensures reliable operation under various environmental conditions, from 0 °C to 40 °C for operation and from -20 °C to 70 °C for storage, making it suitable for Ideal for a wide range of setups. Equipped with five 10/100/1000 ports, of which four support PoE+, the GS105EP can deliver up to 30 W power and is thus suitable for supplying power to devices without additional cables. This switch also has a Web GUI management portal for monitoring and configuration. Its features and standards compliance ensure compatibility and reliability in enterprise and small business environments, underlining its commitment to performance and efficiency.
This text is machine translated.
This text is machine translated.
Features
- Unmanaged
- Quality of Service (QoS) support
- Number of basic switching RJ-45 Ethernet ports: 5
- MAC address table: 2000 entries
- AC/DC Power over Ethernet (PoE)
