NETGEAR GS105EPP-100EUS GS105EPP Network RJ45 switch PoE
EAN:
Part number:
Item no:
NETGEAR GS105EPP unmanaged gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) desktop/wall mounting gray
Highlights & Details
- Supports 128 VLANs and 64 IP multicast groups
- Offers 4 PoE+ ports and a total PoE power of 120 W.
- Fanless design for noiseless operation
- Web GUI management portal for easy device configuration
- Meets several international standards
Technical specifications
- Form factor: Desktop/wall mounting
- Energy source AC / DC
- Product type
Network RJ45 switch
- Working principle
Unmanaged switch
- IEEE 802.3af PoE
4
- 10/100/1000 Mbps ports
5 x
- Jumbo frames
Yes
- Router features
PoE
- MAC addresses
2000
- Weight
400 g
- Width
158 mm
- Height
27 mm
- Depth
101 mm
- Type
GS105EPP
- Factory colour
Grey
- Material (details)
Metal
- UKCA
yes
- Power over Ethernet (PoE) ports quantity
4
- Fanless
yes
- Operating temperature (T-T)
0 - 40 °C
- Basic switching RJ-45 Ethernet ports quantity
5
- Total Power over Ethernet (PoE) budget
120 W
- Packet buffer memory
0.192 MB
- Storage relative humidity (H-H)
0 - 95 %
- Heat dissipation
3.24 BTU/h
- Jumbo frames
9216
- Power over Ethernet (PoE) power per port
30 W
- Bandwidth
10 Gbit/s
- Flow control support
yes
- Power over Ethernet (PoE)
yes
- Quality of Service (QoS) support
yes
- Port mirroring
yes
- Link aggregation
yes
- Stackable
no
- Jumbo frames support
yes
- Broadcast storm control
yes
- Store-and-forward
yes
- Rate limiting
yes
- Manual
yes
- Quick start guide
yes
- Rack mounting
no
- Mean time between failures (MTBF)
853770 h
- Full duplex
yes
- MAC address table
2000 Eintragungen
- IGMP snooping
yes
- Operating altitude
0 - 3000 m
- Operating relative humidity (H-H)
0 - 90 %
- VLAN support
yes
- 10G support
no
- Storage temperature (T-T)
-20 - 70 °C
- Power consumption (max)
137.8 W
- Power supply included
no
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3773444 NETGEAR GS105EPP-100EUS GS105EPP Network RJ45 switch PoE
Description
The NETGEAR Easy Smart GS105EPP was developed to improve the network functions with its functions and its reliable performance. This switch supports up to 128 VLANs and 64 IP multicast groups, making Ideal suitable for creating custom network segments. Its 5 ports enable seamless connectivity, with one being reserved for 10/100/1000 Mbit/s and four PoE+ supporting device integration. With a power consumption of 120 W and the ability to supply non-disruptive PoE, this switch can easily power devices such as IP cameras and wireless access points without additional power sources. The GS105EPP is equipped with a fan-less design for a noiseless operation and a robust metal casing and is thus both efficient and robust. It has management functions via a Web GUI management portal and ensures network efficiency with functions such as IGMP snooping, VLAN support and Quality of Service (QoS). This switch complies with various international standards and ensures reliable operation in different environments, making it Ideal suitable for home office equipment or small business networks.
This text is machine translated.
This text is machine translated.
Features
- Unmanaged
- Quality of Service (QoS) support
- Number of basic switching RJ-45 Ethernet ports: 5
- 1000BASE-T, 100BASE-T, 10BASE-T
- MAC address table: 2000 entries
- Desktop-/Wall mounting
- AC/DC Power over Ethernet (PoE)
