NETGEAR GS105P-300EUS GS105P Network RJ45 switch PoE
EAN:
Part number:
Item no:
NETGEAR GS105P unmanaged gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) desktop/wall mounting gray
Highlights & Details
- Supports Power over Ethernet for supplying power to devices directly via the network cable
- Fanless design ensures a silent operation in the office or at home
- Five ports, including four PoE+ ports, for versatile connectivity options
- Robust metal casing provides for a long life and long-lasting performance
- Designed for a wide range of environments with a wide operating temperature range
Technical specifications
- Form factor: Desktop/wall mounting
- Energy source AC / DC
- Product type
Network RJ45 switch
- LAN transfer rate
10 MBit/s
100 MBit/s
1000 MBit/s
- Working principle
Unmanaged switch
- IEEE 802.3af PoE
4
- 10/100/1000 Mbps ports
5 x
- Jumbo frames
Yes
- Router features
PoE
- MAC addresses
2000
- Weight
400 g
- Width
158 mm
- Height
27 mm
- Depth
101 mm
- Type
GS105P
- Factory colour
Grey
- Material (details)
Metal
- UKCA
yes
- Power over Ethernet (PoE) ports quantity
4
- Fanless
yes
- Operating temperature (T-T)
0 - 40 °C
- Basic switching RJ-45 Ethernet ports quantity
5
- Total Power over Ethernet (PoE) budget
83 W
- Packet buffer memory
0.128 MB
- Storage relative humidity (H-H)
0 - 95 %
- Heat dissipation
3.24 BTU/h
- Jumbo frames
9216
- Power over Ethernet (PoE) power per port
30 W
- Bandwidth
10 Gbit/s
- Flow control support
yes
- Power over Ethernet (PoE)
yes
- Quality of Service (QoS) support
yes
- Port mirroring
yes
- Link aggregation
yes
- Stackable
no
- Jumbo frames support
yes
- Broadcast storm control
yes
- Store-and-forward
yes
- Rate limiting
yes
- Quick start guide
yes
- Rack mounting
no
- Mean time between failures (MTBF)
4113947 h
- Full duplex
yes
- MAC address table
2000 Eintragungen
- IGMP snooping
yes
- Operating altitude
0 - 3000 m
- Operating relative humidity (H-H)
0 - 90 %
- VLAN support
yes
- 10G support
no
- Storage temperature (T-T)
-20 - 70 °C
- Power consumption (max)
67.5 W
- Power supply included
no
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3773445 NETGEAR GS105P-300EUS GS105P Network RJ45 switch PoE
Description
The NETGEAR GS105P is a versatile switch, which provides reliable performance and extensive functions for an improved network experience. It supports Power over Ethernet (PoE+) with a power of 63 W and thus enables a smooth power supply of the connected devices with a simultaneous maintenance of an efficient data communication. This switch has a total of 5 ports, including 4 PoE+-enabled ports, and is thus suitable for various applications such as VoIP and security cameras. Its fan-less design provides for a low-noise operation, while the robust metallic casing offers a long life for every environment.
This switch can be operated at temperatures from 0 °C to 40 °C and is designed for different humidity conditions so that it can be used in different environments. With a non-blocking architecture and support for Jumbo frames it offers a bandwidth performance of 10 Gbit/s, which is suitable for demanding network tasks. The plug-and-play functionality simplifies the installation, while comprehensive compliance with various standards ensures compatibility and reliability in your network configuration.
This text is machine translated.
This switch can be operated at temperatures from 0 °C to 40 °C and is designed for different humidity conditions so that it can be used in different environments. With a non-blocking architecture and support for Jumbo frames it offers a bandwidth performance of 10 Gbit/s, which is suitable for demanding network tasks. The plug-and-play functionality simplifies the installation, while comprehensive compliance with various standards ensures compatibility and reliability in your network configuration.
This text is machine translated.
Features
- Unmanaged
- Quality of Service (QoS) support
- Number of basic switching RJ-45 Ethernet ports: 5
- 1000BASE-T, 100BASE-T, 10BASE-T
- MAC address table: 2000 entries
- Desktop-/Wall mounting
- AC/DC Power over Ethernet (PoE)
