NETGEAR GS348TP-200EUS GS348TPv2 Network SFP switch 104 Gbit/s PoE
EAN:
Part number:
Item no:
NETGEAR GS348TPv2 managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U black
Highlights & Details
- 48 10/100/1000 Mbps ports with PoE+ support
- 380 W PoE power budget for power supply to devices
- Advanced security features, including access control list support
- Efficient cooling with integrated fans
- Conforms to several industry standards
Technical specifications
- Form factor: 1U
- Number of fans: 2 fans
- Memory type: RAM
- Power source: PoE
- Product type
Network SFP switch
- LAN transfer rate
1000 MBit/s
- Transfer rate
104 Gbit/s
- Working principle
Managed switch
- Ethernet ports
48
- PoE ports
48
- SFP ports
4 x
- 10/100/1000 Mbps ports
48 x
- Router features
PoE
- MAC addresses
16000
- Weight
4.05 kg
- Width
440 mm
- Height
43 mm
- Depth
316 mm
- Type
GS348TPv2
- Interfaces
RJ45
- Factory colour
Black
- Max. ambient temperature
50 °C
- Min. ambient temperature
0 °C
- Max. operating noise
36.3 dB
- CPU speed
800 MHz
512 MB
- UKCA
yes
- Operating temperature (T-T)
0 - 50 °C
- Power over Ethernet plus (PoE+) ports quantity
48
- Basic switching RJ-45 Ethernet ports quantity
48
- Total Power over Ethernet (PoE) budget
380 W
- Packet buffer memory
1.5 MB
- Storage relative humidity (H-H)
0 - 95 %
- Auto-negotiation
yes
- Switching capacity
104 Gbit/s
- Loop protection
yes
- ARP inspection
yes
- Shipping (inner) case width
56.7 cm
- Shipping (inner) case length
24.1 cm
- Shipping (inner) case height
43.2 cm
- Products per shipping (inner) case
2 Stück(e)
- Shipping (inner) case net weight
13.3 kg
- SFP module slots quantity
4
- Flow control support
yes
- Power over Ethernet (PoE)
yes
- Quality of Service (QoS) support
yes
- Port mirroring
yes
- Link aggregation
yes
- Jumbo frames support
yes
- Multicast support
yes
- Broadcast storm control
yes
- Web-based management
yes
- Store-and-forward
yes
- Access Control List (ACL)
yes
- Rate limiting
yes
- Manual
yes
- Quick start guide
yes
- Rack mounting
yes
- Full duplex
yes
- Flash memory
64 MB
- MAC address table
16000 Eintragungen
- IGMP snooping
yes
- Number of VLANs
256
- Spanning tree protocol
yes
- Operating altitude
0 - 3000 m
- Operating relative humidity (H-H)
0 - 95 %
- VLAN support
yes
- Storage temperature (T-T)
-20 - 70 °C
- Built-in processor
yes
- User guide
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3733387 NETGEAR GS348TP-200EUS GS348TPv2 Network SFP switch 104 Gbit/s PoE
Description
The NETGEAR GS348TPv2 has been developed for efficient network management and power supply and it has 48 10/100/1000 Mbit/s Ethernet ports with PoE+ functionality. This switch enables a PoE-power consumption of 380 W and is thus suitable for power-intensive applications while ensuring optimum performance. With redundancy functions like double firmware images as well as extended functions for traffic control like IGMP-Snooping and VLAN-support the switch offers a flexible and seamless network connectivity. The NETGEAR GS348TPv2 is designed for different environmental conditions and works efficiently in a temperature range from 0 °C to 50 °C at an air humidity of 95 %. Its long average operating time between failures (MTBF) of over 1.4 million hours contributes to its reliability and makes it suitable for different installations. In addition, its intelligent cooling system with integrated fans ensures that the device remains cool under operating loads, WAS extends its life even further.
