NXP Semiconductors MPXA4100A6U Pressure sensor 1 pc(s) 20 kPa up to 105 kPa SMD
EAN:
Part number:
Item no:
Product type
Pressure sensor
Connector
SMD
Model
Absolute pressure
Pressure reading range (max.)
105 kPa
Min. operating voltage
4.85 V DC
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 26.88
3
4% = € 1.17
€ 25.71
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 26.88 / piece)
€ 26.88
plus VAT.
14-day return policy included
Technical specifications
- Manufacturer: Freescale®
- Product type
Pressure sensor
- Type
MPXA4100A6U
- Connector
SMD
- Model
Absolute pressure
- Output signal (min.)
0.3 V
- Output signal (max.)
4.9 V
- Pressure reading range (min.)
20 kPa
- Pressure reading range (max.)
105 kPa
- Pressure reading range
20 kPa up to 105 kPa
- Min. operating voltage
4.85 V DC
- Max. operating voltage
5.35 V DC
- Operating voltage
4.85 - 5.35 V DC
- Min. temperature
-40 °C
- Max. temperature
+125 °C
- Output voltage
0.3 V at 20 kPa/4.9 V at 105 kPa V
- Tolerance
1.8 %
- Type
MPXA4100A6U
- Temperature range
-40 - +125 °C
- Reading range
20 - 105 kPa
Documents & Downloads
Datasheet
Datasheet 150110 NXP Semiconductors MPXA4100A6U Pressure sensor 1 pc(s) 20 kPa up to 105 kPa SMD
Description
The absolute pressure sensor MPXS4100/MPXA4100 already includes an operational amplifier and resistor networks for accurate, temperature-compensated signal output. The output voltage is proportional to the pressure measurement and varies from 0.3 V at 20 kPa to 4.9 V at 105 kPa. This allows it to be connected directly to displays, A/D converters and microprocessor systems with a minimum of external components.
