OBO Bettermann 2007436 Junction box (L x W) 102 mm x 136 mm 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Max. Conductor cross-section of 10 mm²
- Length = 102 mm
- Width = 136 mm
- Depth = 57 mm
- The number of entries = 10
- Color = gray
- IP66 degree of protection (IP) =
- Sealable = Yes
- Product type
Junction box
- Features
Sealable
- Content
1 pc(s)
- Factory colour
Grey
- Dim
(L x W x H) 102 x 136 x 57 mm
- Length
102 mm
- Width
136 mm
- Height
57 mm
- Depth
57 mm
IP66
Wall-/ceiling mounting
Grey
116
TRUE
67 mm
Rectangular
Untreated
500 V
150 m
-5-60 °C
Plastic
FALSE
IP66
None
None
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1961285 OBO Bettermann 2007436 Junction box (L x W) 102 mm x 136 mm 1 pc(s)
Description
The cable junction box are made of polypropylene, a thermoplastic plastic, and plug-in gaskets made of ethylene vinyl acetate EVA. Lines can be directly through the 10 x M25 seals can be installed or the seals are cut with a knife to the points intended to an introduction opening for wires or pipes. Alternatively, you can cable glands through the openings in inserted instead of the seals and from the inside with a locknut countered. The cable junction box can with sheet-metal screws 3.5 x 9.5 in holes on mounting plates can be mounted. Cover with labelling field. With terminal strip
