OBO Bettermann 3498768 Easy M6 Cavity toggle 40 mm 6 mm 50 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Material = Steel
- Drill hole diameter = 10 mm
- Dowel length = 40 mm
- With thread = Yes
- Thread (metric) = 6
- With screw = No
- (Ø)
6 mm
- Product type
Cavity toggle
- Material
Steel
- Length
40 mm
- Screw diameter
10 mm
- Dim
(Ø x L) 6 mm x 40 mm
- Content
50 pc(s)
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1963711 OBO Bettermann 3498768 Easy M6 Cavity toggle 40 mm 6 mm 50 pc(s)
Description
Cavity toggle easy for installation in prestressed concrete hollow floor slabs. When tightening screw or nut, the cone from the anchor sleeve released, and in this drawn. This spread to the wall plugs in the cavity and creates a form closure. The Holhdeckenanker can also be used if the spreading range not in a hollow chamber. The Component Attachment can be used with standard screws and threaded rods. General Technical Approval Z -21.1-1785 of the DIBt, Berlin, including permissible loads under fire stress up to a fire resistance of 120 minutes.
