OBO Bettermann 5099609 V20-C 0-280 Surge arrester 20 kA 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- The highest continuous voltage AC: 280 V
- The highest continuous voltage DC: 350V
- Size: 1 TE
- Protection level L-N: 1.4 kV
- With remote signalling contact: no
- Signaling on the device: optical
- Test class type 2: yes
- Product type
Surge arrester
- Leakage current
20 kA
- Nominal voltage
230 V AC
- Type
Installation type: on the basis of element
- Operating temperature
-40 to +80 °C
IP20
- Manufacturer part #
5099609
- Factory colour
White
- Dim
(W x H x D) 17.5 x 45 x 48 mm
- Width
17.5 mm
- Height
45 mm
- Depth
48 mm
- Content
1 pc(s)
- Weight
0.09
On basic element
IP20
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1963002 OBO Bettermann 5099609 V20-C 0-280 Surge arrester 20 kA 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1963002 OBO Bettermann 5099609 V20-C 0-280 Surge arrester 20 kA 1 pc(s)
Description
VDE-tested, plug-in upper part, upper part without tools from the lower part, including thermal and dynamic Disconnection device disconnects and visual defect display, high power conductivity with long life span
