Omnitronic Airbro 5,8G
EAN:
Part number:
Item no:
Technical specifications
- Type: Receiver. Battery type 1 x Lithium-Ion 400 mAh
- Battery: Operating time up to 4h; charging time 2h
- Frequency range: 20 - 20 000 Hz
- Range: Up to 15 m in buildings; up to 30 m in the open
- Frequency band: 5.8 GHz
- Parallel operation: Max. 4 transmitter
- Latency: Less than 6 ms
- Status LED: Charging status indicator
- Connections: Output: 6.3-mm jack (unbalanced)
- Max. Level: Output: +770 mV, unbal.
- USB-connection: Type micro-USB (W) in-built version
- Dim
(W x H x D) 138 x 43 x 27 mm
- Weight
90 g
- Width
138 mm
- Height
43 mm
- No. of frequencies (adjustable)
4
- Channels
4
- Depth
27 mm
30 m
- Interfaces
6.3 mm jack out
- No of. 6.3 mm microphone inputs
1 x
- Transmission frequency
5.8 GHz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3729771 Omnitronic Airbro 5,8G
Description
Plug-N-Play wireless receiver. Replaces the cable between the instrument and guitar amplifier. Allows a lot of freedom of movement with the live performance. Ready to use in comfort and quickly thanks to one-button operation. Operates in the interference-free 5.8 GHz band. 24 bit/48 kHz for the ultimate sound quality. 4 switchable transmission Channels Several receivers can be coupled to a single transmitter. Angle adjustable by 195°, thus suitable for all types of guitar Operation time up to 4h. Range of up to 15m inside buildings. Range of up to 30m outdoors. 5.8 GHz world-wide registration and call free. Up to 4 transmitters can be operated in parallel without interferences. Extremely low latency.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1 x device
- 1x user manual
- 1x USB cable
- 1 x Screwdriver
- 1 x pouch.
