Omnitronic CSR-8W Flush mount full range speaker 10 W White 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- RMS. Power 10 W
- Sensitivity 94 dB
- Impedance: ELA technology 100 V
- Power tapping: 5 W; 10 W RMS can be selected via screw clamp
- 1 x 8" woofer
- Speaker type: Built-in speaker
- Material: plastic
- Colour: White
- Installation dimensions Ø 21.5 cm
- Product type
Flush mount full range speaker
- Type
Round
- RMS capacity
10 W
- Max. load
10 W
- Power levels
5 W; 10 W W
- Max. sound pressure
107 dB
- Features
Recessed speaker
- Frequency range
50 - 20000 Hz
- Operating voltage
100 V
- Factory colour
White
- Material
Plastic
- Weight
0.95 kg
- (Ø)
232 mm
- Dim
(Ø) 232 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3729757 Omnitronic CSR-8W Flush mount full range speaker 10 W White 1 pc(s)
Description
8"-broadband in-built loudspeaker, ELA technology 100V, 10 W RMS, Ø 21.5 cm. 20 cm wide-band speaker (8"). Easy to install, similar to common panel-mounted lights. Impact-resistant polystyrene case with protective grille. For voice and background music indoors. Applications include: Installation; restaurants, bars and hotels; sports centers/gyms.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1x user manual
- 1 x speaker
