Omnitronic CSUB-10 PA ceiling speaker 180 W 100 V White 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
CSUB-10 Ceiling Subwoofer
- 10 inch built-in speaker
- Double voice coil
- 90 W RMS
- 2 x 8 Ohm
- Built-in speaker for bass support of sound systems
Technical specifications
- Load capacity: 90 W RMS load capacity: 180 W nominal program components: 25cm woofer (10"), 24 oz Magnet Connection: Spring Terminals impedance: 2 x 8 Ohm Sensitivity: 89 dB dimensions (L x W x H): 303 x 303 x 97 mm mounting cutout: 268 x 268 mm installation depth: 90 mm weight: 2.4 kg size of the low toner: 25 cm (10") Frequency range 30 - 4000 Hz Height: 9.7 cm depth: 30.3 cm Width: 30.3 cm loudspeaker control: 8 Ohm
- Product type
PA ceiling speaker
- Type
Square
- RMS capacity
90 W
- Max. load
180 W
- Impedance
8 Ω
- Max. sound pressure
89 dB
- Frequency range
30 - 4000 Hz
- Operating voltage
100 V
- Factory colour
White
- Material
Plastic
- Weight
2.4 kg
- Length
30.3 cm
- Wireless charging
No
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1875849 Omnitronic CSUB-10 PA ceiling speaker 180 W 100 V White 1 pc(s)
Description
CSUB-10 Ceiling Subwoofer
This text is machine translated.
This text is machine translated.
Features
- Double voice coil 2 x 8 Ohm
- Simple and secure mounting via screw terminals
- Flat profile for inconspicuous installation
- Plastic casing with metal grille
- For ceiling thicknesses up to 30 mm
- For system integration is a frequency crossover required
- Suitable transformers for use in 100-V systems are available as accessories.
