Omnitronic EP-220PR PA preamplifier 5-channel
EAN:
Part number:
Item no:
Highlights & Details
Omnitronic EP-220PR Pre-amplifier with MP3-Player and FM-Radio
- Integrated audio player with Bluetooth-receiverIntegrated Bluetooth audio streaming for wireless music enjoymentSD card slot and USB port5 stereo line inputs4 cinch sockets L/R on the back and 3.5-mm jack connection on the front sideAudio source switchRegulator for volume, basses and trebles1 microphone input with controls for volume, basses and trebles on the front side
Technical specifications
- 5 ChannelsChannels (details): 5 x stereo via phono or jack or player, channel control via control dial; 1 x mono via XLR or jack, channel control via control dialPower supply 115/230 V AC 50/60 HzTotal connected wattage 5 WPower connection: Power feed via cold devices (M) Installation version Power connection cable with safety plug (supplied)Frequency range: 20 - 20 000 HzSignal-to-noise ratio> 100 dBHarmonic distortion factor<: 0.1 % with 1 kHzImpedance: Input 10 kOhm , unbalanced; input 20 kOhm , balancedEqualizer:Master:1 x controls 2-band stereoInputs: Line via 4 x RCA (W) panel jack; microphone via 1 x 3-pin XLR/6.35mm jack (W) combo jack panel version; Line via 1 x 3.5 mm jack socket (stereo) panel versionOutputs: Line via 1 x stereo RCA; line via 1 x 3-pin XLR; line via 1 x 6.3 mm jack plug (stereo) panel versionChannels input: 5 x stereo via phono or jack or player, channel control via rotary knob; 1 x mono via XLR or jack, channel control via control dialInput sensitivity: 1 V.Housing design (19") 48.3 cm Rack installation 1 HEMusic player USB + SD + Bluetooth + FM RadioAudio player – music format: WAV; MP3; WMAAudioplayer - carrier frequency: 2.4 GHzAudio player - Suitable storage media: USB devices/SD cards max. 32 GB (FAT 16/32)Audio player - range: 10 m Bluetooth
- Product type
PA preamplifier
- Dim
(L x W x H) 48.3 x 48.3 x 4.45 cm
- Weight
1.87 kg
- No. of channels
5-channel
- Width
48.3 cm
- Height
4.45 cm
- Length
48.3 cm
- Interfaces
RCA in
XLR in
3.5 mm jack in
RCA out
XLR out
6.3 mm jack out
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2632004 Omnitronic EP-220PR PA preamplifier 5-channel
Description
PRE-AMPLIFIER WITH MP3-PLAYER AND FM-RADIO Acoustic system made simpleWant to control the sound of your restaurant, gym or shop in a simple way? Make the Omnitronic EP-220PR preamplifier your easy-to-use switching center!PLAY MUSICTransfer music wirelessly from your tablet, mobile phone or PC. Load MP3s from an SD card or USB stick and play them using the built-in audio player. Or simply use the 5 switchable line inputs (phono and 3mm jack) to feed external sources. The built-in tuner offers you the possibility of receiving radio programs on the FM-wave.SIMPLE OPERATIONYou can easily control the volume, bass and treble of the music using the controls on the front of the device. A microphone input (XLR) is available for announcements or presentations. You can control the volume, basses and trebles of the microphone signal with the buttons on the front.Thanks to the simple design, the rack rails placed on the sides and the low weight the EP-220PR pre-amplifier can be integrated easily in your location.
This text is machine translated.
This text is machine translated.
Features
- 3 stereo master outputs(19") 48.3 cm rack installation 1 HEFor application areas like: Trade fair construction and shop building; sports centers/fitness studios; restaurants, bars and hotelsAudio player - Bluetooth: Range up to 10 m.
Scope of delivery
- 1 x amplifier
- 1x user manual
- 1 x declaration of conformity
- 1 x Power cable/power cable
- 1 x Antenna
