Omnitronic HS-62 Compression drive speaker 120 W Grey 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Load capacity: Program: 120 W; nominal: 60W RMS
- Frequency range 120 20000 Hz
- Sensitivity 110 dB (1W/1m)
- Max. Sound pressure 128 dB (100V ELA). Impedance: ELA technique 100V
- Housing color: Grey
- Supporting system: 1x; mounting bracket
- Power tapping: 15W; 30W; 60W RMS can be selected with open cable ends
- Connections: Connection cable with open cable ends
- 6.5" woofer with ferrite magnet
- Basket material: Steel
- Conus material: Weatherproof cardboard / paper; 1" tweeter
- Speaker type: Horn; built-in speakers (wall/ceiling)
- Model: Horn
- Material: PP polypropylene; aluminum
- Product type
Compression drive speaker
- RMS capacity
60 W
- Max. load
120 W
- Max. sound pressure
128 dB
IP66
- Operating voltage
100 V
- Factory colour
Grey
- Material
Polypropylene
- Width
365 mm
- Height
325 mm
- Length
360 mm
- (Ø)
15 cm
- Weight
5800 g
- Dim
(Ø x H) 15 cm x 325 mm
- Features
weatherproof
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3729762 Omnitronic HS-62 Compression drive speaker 120 W Grey 1 pc(s)
Description
Weatherproof 6.5" speaker (IP66) with bracket, PA system 100V, 60 W RMS. 2-way speaker system 15 cm cone speaker (6 ") plus tweeter for extended frequency response. High sound pressure and wide transmission range Sturdy plastic casing For outdoor sound systems, such as sports fields, swimming pools, open air events. With mounting bracket. Aluminium grille in gray. Suitable for outdoor use IP66. For applications such as: Installation.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1 x device
- 1 x screw connection.
