Omnitronic PM-422P DJ mixer
EAN:
Part number:
Item no:
Highlights & Details
Omnitronic PM-422P 4-channel DJ mixer with Bluetooth and USB player
- 4 input channels with gain controller, LED level indicator, 3-band equalizer, cue button and channel faderDJ microphone channel with volume control, 2-band equalizer, on/off and talkover switchIntegrated Bluetooth audio streaming for wireless music enjoymentMP3 player with USB connection and blue LCD displayPreview of all input channels and the master total via adjustable stereo headphone outputCrossfader with assignment switches and adjustable control characteristicsMaster channel with volume and balance control10-digit stereo LED level meter
Technical specifications
- Power supply 100-240 V AC 50/60 HzTotal connected wattage 25 WProtection class SK II.Power connection: Power feed via small devices (M) "razor plug" installation version power connection cable with Euro plug (supplied)Bluetooth controlBluetooth: Version: 4.2 + EDR; Profile: A2DP, AVRCPUSB + Bluetooth audio player Display type: Single-color LCD displayControls: Audio player, talkover, crossfader selection switch, crossfader, crossfader curve switchStatus LED: Channel level display, master level display, CUE, ON AIR, PowerInputs: Line via 6 x stereo cinch; Line/phono via 2 x stereo cinch; microphone via 1 x 6.3 mm jack socket (mono) installation version; audio player via 1 x USB A (W) installed versionOutput: Master via 1 x stereo cinch; Master via 2 x 3-pin XLR; REC. Via 1 x stereo cinch; Booth via 1 x stereo cinch; Headphone via 1 x 6.3 mm jack plug (stereo) built-in versionInput channel: 1 x stereo with line player switch via phono or player, channel control via fader, control 3-band EQ, gain control, CUE switch; 1 x stereo with line switch via phono, channel control via fader, control 3-band EQ, gain control, CUE switch; 2 x stereo with line/phono switch via phono, channel control via fader, control 3-band EQ, gain control, CUE switch1 x mono via jack, channel control via dial, control 2-band EQ, Talkover switch, ON AIR switchMaster output : 1 x stereo via XLR or phono, channel control via rotary dial, balance controlBooth output 1 x Stereo via RCA, channel control via control dial, Cue-Mix functionHeadphone output :1 x stereo via jack, channel control via control dialMUSIC FORMAT : MP3, WAV; WAVCarrier frequency 2.4 GHzUSB-connection type ARange: 10 mHousing design: Table stand housingAudio player - Suitable storage media: USB devices max. 32 GB (FAT 32)
- Product type
DJ mixer
- Dim
(W x H x D) 266 x 105 x 350 mm
- No of. 6.3 mm microphone inputs
1 x
- Weight
3.46 kg
- Principle
4-channel
- Width
266 mm
- Height
105 mm
- Depth
350 mm
- No. of RCA outputs
3 x
- No. of RCA inputs
8 x
- No. of 6.3 mm headphone outputs
1 x
- No. of USB type A ports
1 x
- No of. XLR outputs
2 x
Description
Omnitronic PM-422P Fully equipped beginner's mixer for the narrow purseThe PM-422P is a well-equipped 4-channel DJ mixer for the narrow purse. In addition to the standard functions such as gain controller, LED level indicator, 3-band equalizer, cue button and channel fader, the PM-422P has even more to offer:CONNECTIONS8 line and 2 phono inputs are available via phono sockets. The 4 channels of the PM-422P offer high flexibility during the DJ-set and enable a quick change between several DJs.LISTEN & LIVE RECORDINGMonitoring of the master output is possible via balanced cinch and XLR outputs. The master-independent Rec Out also enables live recording of DJ mixes.WIRELESS TRANSMISSION VIA BLUETOOTHMoreover, the PM-422P offers an MP3 player with USB connection and blue LCD display. The built-in Bluetooth function enables wireless music transfer from mobile phones, tablets or laptops. A microphone input including volume control, 2-band equalizer and talk-over switch for announcements complete the round equipment package.
This text is machine translated.
This text is machine translated.
Features
- Separately controllable monitor output (DJ booth)8 line and 2 phono inputs via phono socketsSymmetric XLR outputs and cinch socketsRecord-output, master-independentCan be controlled via BluetoothSingle-color LCD displayRange of up to 10mTable stand case
Scope of delivery
- 1 x mixers
- 1x user manual
- 1 x Power cable/power cable
- 1 x phono cables
- 1 x declaration of conformity
