Omnitronic PPS-6T PA wall speaker 15 W White 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Load capacity: Nominal 15 W RMS
- Frequency range 185 15500 Hz
- Sensitivity 92 dB (1W/1m)
- Max. Sound pressure level 104 dB
- Impedance: ELA technology 100 V
- Assembly: Easy to install
- Camera system: Lens head mount
- Power tapping: 3.8 W, 7.5 W, 15 W RMS can be selected via screw terminals
- Connections: Input: PA system 100 V via screw connector
- 1 x 6" broadband loudspeaker with ferrite magnet
- Basket material: Steel
- Conus material: Cardboard / paper
- Speaker type: Surface-mount speaker (wall/ceiling)
- Type: Closed box
- Material: Plastic, impact-resistant
- Thread M5 x 10 mm
- Dimensions: Width: 20 cm; depth: 14.2 cm; height: 27.5 cm
- Product type
PA wall speaker
- Type
Square
- RMS capacity
15 W
- Max. load
15 W
- Power levels
3.8 W; 7.5 W; 15 W W
- Max. sound pressure
104 dB
- Features
Ceiling speaker
IP20
- Frequency range
185 - 15500 Hz
- Operating voltage
100 V
- Factory colour
White
- Material
Plastic
- Weight
1700 g
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3729760 Omnitronic PPS-6T PA wall speaker 15 W White 1 pc(s)
Description
Flat 6" broadband wall loudspeaker with bracket, PA system 100V, 15 W RMS. Extremely slim design for wall mounting For voice and background music indoors. Easy to Set Up Metallic grille in white. Shock resistant. M5 thread. With lens head mount
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1 x speaker
- 1 x Operating manual
