Omnitronic PS-30S In-ceiling speaker White 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Connection: 100 V or 8 Ohm
- Speaker: 13 cm (5")
- Nominal power (100 V): 3,8/7, 5/15/30 W RMS
- Nominal power (8 ohm): 30 W RMS
- Sensitivity (1W, 1m): 96 dB, ±3 dB
- Frequency range 150 Hz - 15 kHz
- Protection class: IP 44
- Dimensions (D x D): 178 x 212 mm
- Weight: 0.9 kg
- Shipping weight: 2,200 kg
- Product type
In-ceiling speaker
- Type
Round
- RMS capacity
30 W
- Power levels
3.8/7.5/15/30 W
- Features
Ceiling speaker
IP44
- Operating voltage
100 V
- Factory colour
White
- Material
Plastic
- Weight
900
- (Ø)
178 mm
- Length
212 mm
- Dim
(Ø x L) 178 mm x 212 mm
Documents & Downloads
Datasheet
Datasheet 1375898 Omnitronic PS-30S In-ceiling speaker White 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1375898 Omnitronic PS-30S In-ceiling speaker White 1 pc(s)
Description
Projector speaker.
This text is machine translated.
This text is machine translated.
Features
- 100-V loudspeaker system for wall and ceiling mounting
- For 8-ohm and 100 V systems
- 4-level volume control switch
- Open cable ends
- Swivelling Mounting Bracket
- Weatherproof plastic housing (IP44)
- For Public address system in exterior and interior
