Omnitronic VFM-210AP MK2 Active PA speaker 10 inch 90 W 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Omnitronic VFM-210AP MK2 2-way loudspeaker active TCS
- RMS power:90 W
- Max. power:350 W
- 10 inch
- 116 dB
Technical specifications
- Power supply 230 V AC 50 Hz
- Total connected wattage 350 W
- Protection class SK I
- Power connection: Power feed via cold devices (M) Installation version Power connection cable with safety plug (supplied)
- Device fuse 5 x 20 mm, T 1 A fuse can be replaced
- Load capacity: Program 180 W; nominal 90 W RMS
- Frequency range 55 20000 Hz
- Max. Sound pressure level 116 dB
- Control: IR remote control; Bluetooth
- Bluetooth: Version: 5 with Stereo Link (TWS)
- Bluetooth device name: Omnitronic
- Audio player USB + SD + Bluetooth
- Support system: Flange: Ø 35 mm
- Controls: Power switch, volume control per channel, source switch, tone control, master controller; Audio player
- Status LED Power, clip
- Connections:
- Input: Mic/line via 1 x 3-pin XLR/6.35-mm jack (W) combo jack bushing
- Input: Line via 1 x 3.5 mm jack socket (stereo) Installation version
- Input line via 1 x stereo cinch
- Output: Line via stereo cinch
- Channel input: 1 x mono via XLR or jack, channel control via rotary knob
- 1 x stereo via phono or jack or player, channel control via control dial
- Equaliser Master 1 x 2-band
- Music format MP3, WAV
- Number of files: Max. 999
- Suitable storage media: USB devices/SD cards (FAT 32)
- Speakers:
- 1 x 10" woofer with ferrite magnet
- 1.5" moving coil woofer
- 1 x 1" compression driver tweeter with ferrite magnet
- 1" moving coil compression driver - high tone
- 1" horn connection opening
- Speaker type: Compact box
- Carrying handle:2 pieces
- Material: plastic
- Colour, black
- Remote control Battery:1 x button cell 3.0 V CR2032 Lithium-manganese installed
- Product type
Active PA speaker
- RMS power
90 W
- Max. power
350 W
- Speaker size (inch)
10 inch
- Max. sound pressure
116 dB
- Interfaces
Mic 6.35 mm in
XLR in
3.5 mm jack in
RCA out
- Dim
(W x H x D) 340 x 550 x 330 mm
- Frequency range
55 - 20 000 Hz
- Weight
8250 g
- Content
1 pc(s)
- Width
340 mm
- Height
550 mm
- Depth
330 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3729558 Omnitronic VFM-210AP MK2 Active PA speaker 10 inch 90 W 1 pc(s)
Description
Active 2-way speaker (10") with 90 W RMS for PA and DJ applications with audio player and Bluetooth. 2-way bass reflex system with 25 cm woofer and 2.5 cm compression driver. Class A/B architecture: Optimal sound and strong performance with low weight and compact size. Stereo Bluetooth link for wireless stereo operation with 2 linked systems. SD card slot and USB port 1 adjustable combi input mic/line (XLR/jack). Line input, phono, separately adjustable. 3.5 mm AUX connection. Mixed output for connecting further active boxes. Master controller with 2-band EQ. Can be controlled via IR remote control; Bluetooth. Metallic grille in black. 2 robust carry handles. For applications such as: Mobile DJ's / solo entertainer. Possible application: Standing; monitoring; on stand.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1 x compact box
- 1x remote control
- 1 x battery
- 1 x Power cable/power cable
- 1x user manual
- 1 x declaration of conformity.
