Omron EE-SX1106 Miniature Fork Light Barrier
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Reflective light barrier
Connector
THT
Type
EE-SX1106
Wavelength
950 nm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
2
-
€ 1.50
6
7% = € 0.11
€ 1.39
10
11% = € 0.16
€ 1.34
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 2
Total (€ 1.50 / piece)
€ 3.00
plus VAT.
Technical specifications
- UCEO: 30 V
- UECO: 4.5 V
- Packaging type
Piece
- Product type
Reflective light barrier
- Type
EE-SX1106
- Connector
THT
- Wavelength
950 nm
- Min. temperature
-25 °C
- Max. temperature
+85 °C
- Length
6.4 mm
- Width
4.2 mm
- Height
5.4 mm
- Dim
(L x W x H) 6.4 x 4.2 x 5.4 mm
- Engineering Part No
EESX1106
- Type
Fork light barrier
- Type
EE-SX1106
- Ambient temperature
-25 - +85 °C
- Shaft length
950 nm
- Range
-
- Connection
wired
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 179995 Omron EE-SX1106 Miniature Fork Light Barrier
User & Safety Instructions
User & Safety Instructions 179995 Omron EE-SX1106 Miniature Fork Light Barrier
Description
Optical micro-sensor for example to record rotation count and / or speed, color markers, etc. Also used as a non-contact and contact-less switch.
Hints
For more information on this EE-SX1106, please refer to its datasheet under 'downloadable documents'
