Panasonic ASEN80216 Axial fan 230 V AC 55 m³/h (L x W x H) 80 x 80 x 25 mm
EAN:
Part number:
Item no:
Product type
Axial fan
Nominal voltage
230 V AC
Power
7.6 W
Type of bearing
Double ball bearing
Air flow rate
55 m³/h
Datasheet (PDF)
Total (€ 36.97 / piece)
€ 67.22
-45 %
€ 36.97
plus VAT.
14-day return policy included
Technical specifications
- Product type
Axial fan
- Type
ASEN80216
- Nominal voltage
230 V AC
- Max. current consumption
55 mA
7.6 W
- Type of bearing
Double ball bearing
- Rotational speed
3000 U/min
- Noise emission (max.)
31 dB
- Air flow rate
55 m³/h
- Connection
Open end cable
- Cable length
30.00 cm
- Factory colour
Black
- Material
Aluminium
Plastic
50000 h
- Min. temperature
-20 °C
- Max. temperature
70 °C
- Length
80 mm
- Width
80 mm
- Height
25 mm
- Dim
(L x W x H) 80 x 80 x 25 mm
- Features
w/o rotary encoder
Documents & Downloads
Datasheet
Datasheet 184346 Panasonic ASEN80216 Axial fan 230 V AC 55 m³/h (L x W x H) 80 x 80 x 25 mm
User & Safety Instructions
User & Safety Instructions 184346 Panasonic ASEN80216 Axial fan 230 V AC 55 m³/h (L x W x H) 80 x 80 x 25 mm
Description
Axial direct current exhaust with two precision ball bearings. 2-phase gap motor, impedance protected. Horizontal and vertical installation possible. Die-cast aluminum housing and fanwheel made of reinforced plastic.
This text is machine translated.
This text is machine translated.
Hints
Approvals: UL, CSA.
