Panasonic Electrolytic capacitor Radial lead 1.500 µF 10 V 20 % 1 pc(s)
Part number:
Item no:
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
1.500 µF
Nominal voltage
10 V
Tolerance ±
20 %
Datasheet (PDF)
Highlights & Details
Panasonic Elko 1500uF 10V 12.5x15mm RM5
Our service for you
Technical specifications
- Series FK-A
- Qualification: AEC-Q200
- Design_1: Radial
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: • In aluminum beaker, miniaturized
- • Radial connections
- • Extended temperature range (up to 105°C)
- • Low impedance
- • Long life (at 105°C) 3003...5000 hours
- Wire diameter 0.6 mm.
- Pitch_1:5 mm
- Capacity 1,500 µF
- Capacity_1: 1,500
- Unit of capacity: µF
- Capacity Tolerance 20%
- Ripple current 1,400 mA
- Equivalent Series Resistance (ESR): 48 mOhm
- Nominal voltage DC 10 V
- Lifetime_1: 5,000 h
- Product type
Electrolytic capacitor
- Type
Radial lead
- Capacity (elec.)
1.500 µF
- Nominal voltage
10 V
- Tolerance ±
20 %
- Content
1 pc(s)
- Length
15.0 mm
- RoHS-compliant
Yes
- Type
EEUFK1A152S
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
55 °C
Documents & Downloads
Datasheet
Datasheet 3463354 Panasonic Electrolytic capacitor Radial lead 1.500 µF 10 V 20 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463354 Panasonic Electrolytic capacitor Radial lead 1.500 µF 10 V 20 % 1 pc(s)
Description
Panasonic FK-A capacitors radia
