Panasonic Electrolytic capacitor Radial lead 1.500 µF 25 V 20 % 1 pc(s)
Part number:
Item no:
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
1.500 µF
Nominal voltage
25 V
Tolerance ±
20 %
Datasheet (PDF)
Highlights & Details
Panasonic Elko 1500uF 25V 12.5x20 mm RM5 belt
Our service for you
Technical specifications
- Series FP-A
- Qualification: AEC-Q200
- Design_1: Radial
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: THT
- Delivery form_1: Taped
- Connections_1: 2-pin
- Properties_1: High ripple current
- Large capacity
- Durability: 4000h to 5000h (@105°C)
- Taped version
- Pitch_1:5 mm
- Capacity 1,500 µF
- Capacity_1: 1,500
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.14
- Ripple current 3,250 mA
- Equivalent Series Resistance (ESR): 0.038 ohms
- Nominal voltage DC 25 V
- Lifetime_1: 5,000 h
- Product type
Electrolytic capacitor
- Type
Radial lead
- Capacity (elec.)
1.500 µF
- Nominal voltage
25 V
- Tolerance ±
20 %
- Height
20.0 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
EEUFP1E152B
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
- Certification marks
AEC-Q200
Documents & Downloads
Datasheet
Datasheet 3463371 Panasonic Electrolytic capacitor Radial lead 1.500 µF 25 V 20 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463371 Panasonic Electrolytic capacitor Radial lead 1.500 µF 25 V 20 % 1 pc(s)
Description
Alu Elko series FP
