Panasonic Electrolytic capacitor Radial lead 2.200 µF 35 V 20 % (Ø x L) 16 mm x 25.0 mm 1 pc(s)
Part number:
Item no:
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
2.200 µF
Nominal voltage
35 V
Dim
(Ø x L) 16 mm x 25.0 mm
Datasheet (PDF)
Highlights & Details
Panasonic Elko 2200uF 35V 16x25mm RM7.5
Our service for you
Technical specifications
- Series FK-A
- Qualification: AEC-Q200
- Design_1: Radial
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: • In aluminum beaker, miniaturized
- • Radial connections
- • Extended temperature range (up to 105°C)
- • Low impedance
- • Long life (at 105°C) 3003...5000 hours
- Wire diameter 0.8 mm.
- Pitch_1:7.5 mm
- Capacity 2,200 µF
- Capacity_1: 2,200
- Unit of capacity: µF
- Capacity Tolerance 20%
- Ripple current 2,760 mA
- Equivalent Series Resistance (ESR): 19 mOhm
- Nominal voltage DC 35 V
- Lifetime_1: 5,000 h
- Product type
Electrolytic capacitor
- Type
Radial lead
- Dim
(Ø x L) 16 mm x 25.0 mm
- Capacity (elec.)
2.200 µF
- Nominal voltage
35 V
- Tolerance ±
20 %
- (Ø)
16 mm
- Content
1 pc(s)
- Length
25.0 mm
- RoHS-compliant
Yes
- Type
EEUFK1V222
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
55 °C
Documents & Downloads
Datasheet
Datasheet 3463360 Panasonic Electrolytic capacitor Radial lead 2.200 µF 35 V 20 % (Ø x L) 16 mm x 25.0 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463360 Panasonic Electrolytic capacitor Radial lead 2.200 µF 35 V 20 % (Ø x L) 16 mm x 25.0 mm 1 pc(s)
Description
Panasonic FK-A capacitors radia
