Panasonic Electrolytic capacitor Radial lead 330 µF 6.3 V 20 % 1 pc(s)
Part number:
Item no:
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
330 µF
Nominal voltage
6.3 V
Tolerance ±
20 %
Datasheet (PDF)
Highlights & Details
Panasonic SMD electrolytic capacitor 33UF 6.3V 6.7.7mm
Our service for you
Technical specifications
- Series FK (A)
- Qualification: AEC-Q200
- Design_1: D
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Properties_1: • Low impedance
- • Endurance: 105°C 2000h
- • miniaturized
- • AEC-Q200 compliant
- Capacity 330 µF
- Capacity_1: 330
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.26
- Ripple current 280 mA
- Equivalent Series Resistance (ESR): 0.34 ohms
- Nominal voltage DC 6.3 V
- Lifetime_1: 2,000 h
- Product type
Electrolytic capacitor
- Type
Radial lead
- Capacity (elec.)
330 µF
- Nominal voltage
6.3 V
- Tolerance ±
20 %
- Height
7.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
EEEFKJ331XAP
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
Documents & Downloads
Datasheet
Datasheet 3465906 Panasonic Electrolytic capacitor Radial lead 330 µF 6.3 V 20 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3465906 Panasonic Electrolytic capacitor Radial lead 330 µF 6.3 V 20 % 1 pc(s)
Description
Alu Elko SMD series FK_AR/AP
