Panasonic Electrolytic capacitor Radial lead 470 µF 10 V 20 % (Ø x H) 8 mm x 11.5 mm 1 pc(s)
Part number:
Item no:
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
470 µF
Nominal voltage
10 V
Dim
(Ø x H) 8 mm x 11.5 mm
Datasheet (PDF)
Highlights & Details
Panasonic Elko 470uF 10V 8x11.5mm RM3.5
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series FM-A
- Design_1: Radial
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Pitch_1:3.5 mm
- Capacity 470 µF
- Capacity_1: 470
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.19
- Ripple current 950 mA
- Equivalent Series Resistance (ESR): 0.056 ohms
- Nominal voltage DC 10 V
- Lifetime_1: 3,000 h
- Product type
Electrolytic capacitor
- Type
Radial lead
- Dim
(Ø x H) 8 mm x 11.5 mm
- Capacity (elec.)
470 µF
- Nominal voltage
10 V
- Tolerance ±
20 %
- Height
11.5 mm
- (Ø)
8 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
EEUFM1A471
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
40 °C
Documents & Downloads
Datasheet
Datasheet 3466014 Panasonic Electrolytic capacitor Radial lead 470 µF 10 V 20 % (Ø x H) 8 mm x 11.5 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3466014 Panasonic Electrolytic capacitor Radial lead 470 µF 10 V 20 % (Ø x H) 8 mm x 11.5 mm 1 pc(s)
Description
Panasonic hybrid radial capacitors SE
