Panasonic Electrolytic capacitor Radial lead 5 mm 470 µF 35 V 20 % (Ø x H) 10 mm x 20.0 mm 1 pc(s) Tape
Part number:
Item no:
Packaging type
Tape
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
470 µF
Nominal voltage
35 V
Datasheet (PDF)
Highlights & Details
Panasonic Elko 470uF 35V 10x20 mm RM5 0 mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series FM-A
- Design_1: Radial
- Mounting type_1: THT
- Delivery form_1: Taped
- Connections_1: 2-pin
- Pitch_1:5 mm
- Capacity 470 µF
- Capacity_1: 470
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.12
- Ripple current 2,180 mA
- Equivalent Series Resistance (ESR): 0.019 ohms
- Nominal voltage DC 35 V
- Lifetime_1: 5,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
Radial lead
- CS
5 mm
- Dim
(Ø x H) 10 mm x 20.0 mm
- Capacity (elec.)
470 µF
- Nominal voltage
35 V
- Tolerance ±
20 %
- Height
20.0 mm
- (Ø)
10 mm
- Content
1 pc(s)
- Width
10 mm
- Length
20.0 mm
- RoHS-compliant
Yes
- Type
EEUFM1V471B
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
40 °C
Documents & Downloads
Datasheet
Datasheet 3463369 Panasonic Electrolytic capacitor Radial lead 5 mm 470 µF 35 V 20 % (Ø x H) 10 mm x 20.0 mm 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3463369 Panasonic Electrolytic capacitor Radial lead 5 mm 470 µF 35 V 20 % (Ø x H) 10 mm x 20.0 mm 1 pc(s) Tape
Description
Panasonic hybrid radial capacitors SE
