Panasonic Electrolytic capacitor Radial lead 680 µF 16 V 20 % (Ø x H) 8 mm x 20.0 mm 1 pc(s)
Part number:
Item no:
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
680 µF
Nominal voltage
16 V
Dim
(Ø x H) 8 mm x 20.0 mm
Datasheet (PDF)
Highlights & Details
Panasonic electrolytic capacitor 680UF 16V 8x20mm RM3.5
Our service for you
Technical specifications
- Series FM-A
- Design_1: Radial
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Pitch_1:3.5 mm
- Capacity 680 µF
- Capacity_1: 680
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.16
- Ripple current 1,560 mA
- Equivalent Series Resistance (ESR): 0.3 ohms
- Nominal voltage DC 16 V
- Lifetime_1: 4,000 h
- Product type
Electrolytic capacitor
- Type
Radial lead
- Dim
(Ø x H) 8 mm x 20.0 mm
- Capacity (elec.)
680 µF
- Nominal voltage
16 V
- Tolerance ±
20 %
- Height
20.0 mm
- (Ø)
8 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
EEUFM1C681L
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
40 °C
Documents & Downloads
Datasheet
Datasheet 3466019 Panasonic Electrolytic capacitor Radial lead 680 µF 16 V 20 % (Ø x H) 8 mm x 20.0 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3466019 Panasonic Electrolytic capacitor Radial lead 680 µF 16 V 20 % (Ø x H) 8 mm x 20.0 mm 1 pc(s)
Description
Panasonic hybrid radial capacitors SE
