Panasonic Electrolytic capacitor Radial lead 7.5 mm 1.800 µF 35 V 20 % (Ø x H) 16 mm x 25.0 mm 1 pc(s) Bulk
Part number:
Item no:
Packaging type
Bulk
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
1.800 µF
Nominal voltage
35 V
Datasheet (PDF)
Highlights & Details
Panasonic electrolytic capacitor 1800UF 35V 16x25mm RM7.5
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series FM-A
- Design_1: Radial
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Pitch_1:7.5 mm
- Capacity 1,800 µF
- Capacity_1: 1,800
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.12
- Ripple current 3,820 mA
- Equivalent Series Resistance (ESR): 0.014 ohms
- Nominal voltage DC 35 V
- Lifetime_1: 7,000 h
- Packaging type
Bulk
- Product type
Electrolytic capacitor
- Type
Radial lead
- CS
7.5 mm
- Dim
(Ø x H) 16 mm x 25.0 mm
- Capacity (elec.)
1.800 µF
- Nominal voltage
35 V
- Tolerance ±
20 %
- Height
25.0 mm
- (Ø)
16 mm
- Content
1 pc(s)
- Width
16 mm
- Length
25.0 mm
- RoHS-compliant
Yes
- Type
EEUFM1V182
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
40 °C
Documents & Downloads
Datasheet
Datasheet 3466029 Panasonic Electrolytic capacitor Radial lead 7.5 mm 1.800 µF 35 V 20 % (Ø x H) 16 mm x 25.0 mm 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 3466029 Panasonic Electrolytic capacitor Radial lead 7.5 mm 1.800 µF 35 V 20 % (Ø x H) 16 mm x 25.0 mm 1 pc(s) Bulk
Description
Panasonic hybrid radial capacitors SE
