Panasonic Electrolytic capacitor SMD 100 µF 63 V 20 % (Ø x H) 10 mm x 12.8 mm 1 pc(s) Tape
Part number:
Item no:
Packaging type
Tape
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
100 µF
Nominal voltage
63 V
Datasheet (PDF)
Highlights & Details
Panasonic hybrid SMD electrolytic capacitor 100uF 63V 10X12.8mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series: TOO
- Qualification: AEC-Q200
- Design_1:G12
- Technology: Polymer hybrid aluminum electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Characteristics_1: Conductive polymer-hybrid aluminum electrolytic capacitor
- Endurance: 135°C 4000h
- High capacity as compared to ZS series
- For lead-free high-temperature reflow
- AEC-Q200 compliant
- Vibration-proof product
- Capacity 100 µF
- Capacity_1: 100
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.08
- Ripple current 4,600 mA
- Equivalent Series Resistance (ESR): 0.012 ohms
- Nominal voltage DC 63 V
- Lifetime_1: 4,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 10 mm x 12.8 mm
- Capacity (elec.)
100 µF
- Nominal voltage
63 V
- Tolerance ±
20 %
- Height
12.8 mm
- (Ø)
10 mm
- Content
1 pc(s)
- Material
Polymer
- RoHS-compliant
Yes
- Type
EEHZU1J101V
- Operating temperature (max.)
135 °C
- Operating temperature (min.)
-55 °C
- Certification marks
AEC-Q200 compliant
Documents & Downloads
Datasheet
Datasheet 3463250 Panasonic Electrolytic capacitor SMD 100 µF 63 V 20 % (Ø x H) 10 mm x 12.8 mm 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3463250 Panasonic Electrolytic capacitor SMD 100 µF 63 V 20 % (Ø x H) 10 mm x 12.8 mm 1 pc(s) Tape
Description
Panasonic series ZS HYBRID SMD
