Panasonic Electrolytic capacitor SMD 150 µF 100 V 20 % (Ø x H) 16 mm x 16.5 mm 1 pc(s) #####Tape and Reel
Part number:
Item no:
Packaging type
#####Tape and Reel
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
150 µF
Nominal voltage
100 V
Datasheet (PDF)
Highlights & Details
Panasonic SMD electrolytic capacitor 150UF 100V 16x16.5mm
Our service for you
Technical specifications
- Series FK (A)
- Qualification: AEC-Q200
- Design_1: J16
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Properties_1: • Low impedance
- • Endurance: 105°C 2000h
- • miniaturized
- • AEC-Q200 compliant
- Capacity 150 µF
- Capacity_1: 150
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.07
- Ripple current 793 mA
- Equivalent Series Resistance (ESR): 0.17 ohms
- Nominal voltage DC 100 V
- Lifetime_1: 2,000 h
- Packaging type
#####Tape and Reel
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 16 mm x 16.5 mm
- Capacity (elec.)
150 µF
- Nominal voltage
100 V
- Tolerance ±
20 %
- Height
16.5 mm
- (Ø)
16 mm
- Content
1 pc(s)
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
EEEFK2A151AM
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
Documents & Downloads
Datasheet
Datasheet 3465902 Panasonic Electrolytic capacitor SMD 150 µF 100 V 20 % (Ø x H) 16 mm x 16.5 mm 1 pc(s) #####Tape and Reel
User & Safety Instructions
User & Safety Instructions 3465902 Panasonic Electrolytic capacitor SMD 150 µF 100 V 20 % (Ø x H) 16 mm x 16.5 mm 1 pc(s) #####Tape and Reel
Description
Alu Elko SMD series FK_AR/AP
