Panasonic Electrolytic capacitor SMD 220 µF 50 V 20 % (Ø x H) 10 mm x 16.5 mm 1 pc(s) #####Tape and Reel
Part number:
Item no:
Packaging type
#####Tape and Reel
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
220 µF
Nominal voltage
50 V
Datasheet (PDF)
Highlights & Details
Panasonic hybrid SMD electrolytic capacitor 220UF 50V 10x16.5mm
Our service for you
Technical specifications
- Series ZS
- Qualification: AEC-Q200
- Design_1: G16
- Technology: Polymer hybrid aluminum electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Characteristics_1: Conductive polymer-hybrid aluminum electrolytic capacitor
- Endurance: 125°C 4000h
- High ripple current and high capacity
- For lead-free high-temperature reflow
- AEC-Q200 compliant
- Capacity 220 µF
- Capacity_1: 220
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.1
- Ripple current 3,700 mA
- Equivalent Series Resistance (ESR): 0.013 ohms
- Nominal voltage DC 50 V
- Lifetime_1: 4,000 h
- Packaging type
#####Tape and Reel
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 10 mm x 16.5 mm
- Capacity (elec.)
220 µF
- Nominal voltage
50 V
- Tolerance ±
20 %
- Height
16.5 mm
- (Ø)
10 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
10 mm
- Length
16.5 mm
- RoHS-compliant
Yes
- Max. temperature
125 °C
- Type
EEHZS1H221P
- Operating temperature (max.)
125 °C
- Operating temperature (min.)
-55 °C
- Certification marks
AEC-Q200 compliant
Documents & Downloads
Datasheet
Datasheet 3463227 Panasonic Electrolytic capacitor SMD 220 µF 50 V 20 % (Ø x H) 10 mm x 16.5 mm 1 pc(s) #####Tape and Reel
User & Safety Instructions
User & Safety Instructions 3463227 Panasonic Electrolytic capacitor SMD 220 µF 50 V 20 % (Ø x H) 10 mm x 16.5 mm 1 pc(s) #####Tape and Reel
Description
Panasonic series ZS HYBRID SMD
