Panasonic Electrolytic capacitor SMD 270 µF 35 V 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s) #####Tape and Reel
Part number:
Item no:
Packaging type
#####Tape and Reel
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
270 µF
Nominal voltage
35 V
Datasheet (PDF)
Highlights & Details
Panasonic hybrid SMD electrolytic capacitor 270UF 35V 10x10.2mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series ZE
- Qualification: AEC-Q200
- Design_1: G
- Technology: Polymer hybrid aluminum electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Characteristics_1: Conductive polymer-hybrid aluminum electrolytic capacitor
- Endurance: 2000h at 145°C.
- High-temperature lead-free reflow
- Low ESR and high ripple current
- High electrical strength
- Complies with AEC-Q200
- Vibration-proof design
- Capacity 270 µF
- Capacity_1: 270
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.12
- Ripple current 900 mA
- Equivalent Series Resistance (ESR): 0.02 ohms
- Nominal voltage DC 35 V
- Lifetime_1: 2,000 h
- Capacitor type low ESR
- Packaging type
#####Tape and Reel
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 10 mm x 10.5 mm
- Capacity (elec.)
270 µF
- Nominal voltage
35 V
- Tolerance ±
20 %
- Height
10.5 mm
- (Ø)
10 mm
- Content
1 pc(s)
- Material
Polymer
- Width
10 mm
- Length
10.5 mm
- RoHS-compliant
Yes
- Max. temperature
145 °C
- Type
EEHZE1V271V
- Operating temperature (max.)
145 °C
- Operating temperature (min.)
-55 °C
- Certification marks
AEC-Q200 compliant
Documents & Downloads
Datasheet
Datasheet 3465848 Panasonic Electrolytic capacitor SMD 270 µF 35 V 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s) #####Tape and Reel
Datasheet 3465848 Panasonic Electrolytic capacitor SMD 270 µF 35 V 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s) #####Tape and Reel
User & Safety Instructions
User & Safety Instructions 3465848 Panasonic Electrolytic capacitor SMD 270 µF 35 V 20 % (Ø x H) 10 mm x 10.5 mm 1 pc(s) #####Tape and Reel
Description
PANA ZE Hybrid SMD-Electrolyte-Condensate
