Panasonic Electrolytic capacitor SMD 4.7 µF 35 V 20 % (Ø x H) 4 mm x 5.8 mm 1 pc(s) #####Tape and Reel
Part number:
Item no:
Packaging type
#####Tape and Reel
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
4.7 µF
Nominal voltage
35 V
Datasheet (PDF)
Highlights & Details
Panasonic SMD electrolytic capacitor 4.7UF 35V 4x5.8mm
Our service for you
Technical specifications
- Series FK (A)
- Qualification: AEC-Q200
- Design_1: B
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Properties_1: • Low impedance
- • Endurance: 105°C 2000h
- • miniaturized
- • AEC-Q200 compliant
- Capacity 4.7 µF
- Capacity_1: 4.7
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.12
- Ripple current 90 mA
- Equivalent Series Resistance (ESR): 1.35 ohms
- Nominal voltage DC 35 V
- Lifetime_1: 2,000 h
- Packaging type
#####Tape and Reel
- Product type
Electrolytic capacitor
- Type
SMD
- Dim
(Ø x H) 4 mm x 5.8 mm
- Capacity (elec.)
4.7 µF
- Nominal voltage
35 V
- Tolerance ±
20 %
- Height
5.8 mm
- (Ø)
4 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
4 mm
- Length
5.8 mm
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
EEEFK1V4R7AR
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
Documents & Downloads
Datasheet
Datasheet 3465900 Panasonic Electrolytic capacitor SMD 4.7 µF 35 V 20 % (Ø x H) 4 mm x 5.8 mm 1 pc(s) #####Tape and Reel
User & Safety Instructions
User & Safety Instructions 3465900 Panasonic Electrolytic capacitor SMD 4.7 µF 35 V 20 % (Ø x H) 4 mm x 5.8 mm 1 pc(s) #####Tape and Reel
Description
Alu Elko SMD series FK_AR/AP
