Panasonic Electrolytic capacitor THT 3.5 mm 560 µF 6.3 V 20 % (Ø x H) 8 mm x 11.5 mm 1 pc(s) Bulk
Part number:
Item no:
Packaging type
Bulk
Product type
Electrolytic capacitor
Type
THT
Capacity (elec.)
560 µF
Nominal voltage
6.3 V
Datasheet (PDF)
Highlights & Details
Panasonic Elko 560UF 6.3V 8x11.5 mm RM3.5
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series FC-A
- Qualification: AEC-Q200
- Design_1: Radial
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Pitch_1:3.5 mm
- Capacity 560 µF
- Capacity_1: 560
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.22
- Ripple current 555 mA
- Equivalent Series Resistance (ESR): 0.117 ohms
- Nominal voltage DC 6.3 V
- Lifetime_1: 2,000 h
- Packaging type
Bulk
- Product type
Electrolytic capacitor
- Type
THT
- CS
3.5 mm
- Dim
(Ø x H) 8 mm x 11.5 mm
- Capacity (elec.)
560 µF
- Nominal voltage
6.3 V
- Tolerance ±
20 %
- Height
11.5 mm
- (Ø)
8 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
8 mm
- Length
11.5 mm
- RoHS-compliant
Yes
- Type
EEUFC0J561
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
- Certification marks
AEC-Q200
Documents & Downloads
Datasheet
Datasheet 3465948 Panasonic Electrolytic capacitor THT 3.5 mm 560 µF 6.3 V 20 % (Ø x H) 8 mm x 11.5 mm 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 3465948 Panasonic Electrolytic capacitor THT 3.5 mm 560 µF 6.3 V 20 % (Ø x H) 8 mm x 11.5 mm 1 pc(s) Bulk
Description
Alu Elko series UFC
