Panasonic Electrolytic capacitor THT 5 mm 22 µF 50 V 20 % (Ø x H) 5 mm x 11.0 mm 1 pc(s) Tape
Part number:
Item no:
Packaging type
Tape
Product type
Electrolytic capacitor
Type
THT
Capacity (elec.)
22 µF
Nominal voltage
50 V
Datasheet (PDF)
Highlights & Details
Panasonic Elko 22uF 50V 5x11mm RM5 0 mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series FC-A
- Qualification: AEC-Q200
- Design_1: Radial
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: THT
- Delivery form_1: Taped
- Connections_1: 2-pin
- Pitch_1:5 mm
- Capacity 22 µF
- Capacity_1: 22
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.1
- Ripple current 155 mA
- Equivalent Series Resistance (ESR): 1.3 ohms
- Nominal voltage DC 50 V
- Lifetime_1: 1,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
THT
- CS
5 mm
- Dim
(Ø x H) 5 mm x 11.0 mm
- Capacity (elec.)
22 µF
- Nominal voltage
50 V
- Tolerance ±
20 %
- Height
11.0 mm
- (Ø)
5 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
5 mm
- Length
11.0 mm
- RoHS-compliant
Yes
- Type
EEUFC1H220B
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
- Certification marks
AEC-Q200
Documents & Downloads
Datasheet
Datasheet 3463344 Panasonic Electrolytic capacitor THT 5 mm 22 µF 50 V 20 % (Ø x H) 5 mm x 11.0 mm 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3463344 Panasonic Electrolytic capacitor THT 5 mm 22 µF 50 V 20 % (Ø x H) 5 mm x 11.0 mm 1 pc(s) Tape
Description
Alu Elko series UFC
