Panasonic Electrolytic capacitor THT 7.5 mm 2.200 µF 16 V 20 % (Ø x H) 16 mm x 20.0 mm 1 pc(s) Bulk
Part number:
Item no:
Packaging type
Bulk
Product type
Electrolytic capacitor
Type
THT
Capacity (elec.)
2.200 µF
Nominal voltage
16 V
Datasheet (PDF)
Highlights & Details
Panasonic Elko 2200uF 16V 16X20mm RM7,5
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series FC-A
- Qualification: AEC-Q200
- Design_1: Radial
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Pitch_1:7.5 mm
- Capacity 2,200 µF
- Capacity_1: 2,200
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.16
- Ripple current 2,205 mA
- Equivalent Series Resistance (ESR): 0.029 ohms
- Nominal voltage DC 16 V
- Lifetime_1: 5,000 h
- Packaging type
Bulk
- Product type
Electrolytic capacitor
- Type
THT
- CS
7.5 mm
- Dim
(Ø x H) 16 mm x 20.0 mm
- Capacity (elec.)
2.200 µF
- Nominal voltage
16 V
- Tolerance ±
20 %
- Height
20.0 mm
- (Ø)
16 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
16 mm
- Length
20.0 mm
- RoHS-compliant
Yes
- Type
EEUFC1C222S
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
- Certification marks
AEC-Q200
Documents & Downloads
Datasheet
Datasheet 3465963 Panasonic Electrolytic capacitor THT 7.5 mm 2.200 µF 16 V 20 % (Ø x H) 16 mm x 20.0 mm 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 3465963 Panasonic Electrolytic capacitor THT 7.5 mm 2.200 µF 16 V 20 % (Ø x H) 16 mm x 20.0 mm 1 pc(s) Bulk
Description
Alu Elko series UFC
