Panasonic ERJ8BQF3R3V SMD resistor 3.3 Ω SMD 1206 0.5 W 1 % 200 ppm/°C 1 pc(s) Tape
Part number:
Item no:
Packaging type
Tape
Product type
SMD resistor
Type
1206
Resistance
3.3 Ω
Power rating
0.5 W
Datasheet (PDF)
Highlights & Details
Panasonic SMD-thickness layer 1206 0.5W 1% 3.3R
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series: ERJ8B
- Design 1206
- Delivery type: Belt
- Weight: 0.01 g
- Resistance tolerance: ±1 %
- Rated output: 0.5 W
- Load reduction: Linear from 70°C to 155°C (0W)
- Qualification: AEC-Q200
- Packaging type
Tape
- Product type
SMD resistor
- Type
SMD
- Type
1206
- Resistance
3.3 Ω
- Power rating
0.5 W
- Tolerance ±
1 %
- Temperature coefficient
200 ppm/°C
- Length
3.2 mm
- Width
1.6 mm
- Height
0.6 mm
- Content
1 pc(s)
- Dim
(L x W x H) 3.2 x 1.6 x 0.6 mm
- RoHS-compliant
Yes
- Type
ERJ8BQF3R3V
- Operating temperature (max.)
155 °C
- Operating temperature (min.)
55 °C
Documents & Downloads
Datasheet
Datasheet 3464819 Panasonic ERJ8BQF3R3V SMD resistor 3.3 Ω SMD 1206 0.5 W 1 % 200 ppm/°C 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3464819 Panasonic ERJ8BQF3R3V SMD resistor 3.3 Ω SMD 1206 0.5 W 1 % 200 ppm/°C 1 pc(s) Tape
Description
Panasonic SMD Thick Film Resistors ER
This text is machine translated.
This text is machine translated.
Features
- SMD Thick Film Resistors
- Small and lightweight current measuring resistors
- High reliability due to metallized thick film resistor element and three electrode layers
- Series ERJ8BW/CW_: Improved resistance to pulse behavior
- Reflow and surge solderable
