Panasonic MA155MT88X11 MA155MT88X11 Limit switch 400 V AC 10 A Steel lever (straight) momentary IP66 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 29.65
3
4% = € 1.29
€ 28.36
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 29.65 / piece)
€ 29.65
plus VAT.
14-day return policy included
Technical specifications
- Product type
Limit switch
- Connection
Screws
- Operation type
Steel lever (straight)
- Switching voltage
400 V AC
- Switching current (max.)
10 A
- Contact type
1 maker
1 breaker
- Contact opening
Snap-action contact
- Functions
momentary
IP66
- Thread size
M16
- Durability
1 x 107 cycles
- Material
Metal
- Dim. (add. text)
Body
- Width
30 mm
- Type
MA155MT88X11
- Content
1 pc(s)
- Dim
(W x H x D) 30 x 60 x 30 mm (Body)
- Height
60 mm
- Depth
30 mm
Documents & Downloads
Datasheet
Datasheet 284326 Panasonic MA155MT88X11 MA155MT88X11 Limit switch 400 V AC 10 A Steel lever (straight) momentary IP66 1 pc(s)
Description
Limit switch for standard and safety applications with separate actuator. Head can be rotated in 90° steps. Frontal or vertical actuation.
This text is machine translated.
This text is machine translated.
Hints
Approvals: UL, CSA, standards: IEC 947-5-1, EN60947-5-1.
