Panasonic MKP thin film capacitor Radial lead 1 µF 630 V 5 % (L x W x H) 31.5 x 9.5 x 18.0 mm 1 pc(s)
Part number:
Item no:
Product type
MKP thin film capacitor
Type
Radial lead
Capacity (elec.)
1 µF
Nominal voltage
630 V
Dim
(L x W x H) 31.5 x 9.5 x 18.0 mm
Datasheet (PDF)
Highlights & Details
Panasonic MKP 1uF 630V 5% RM27.5
Our service for you
Technical specifications
- Series ECWFG
- Qualification: AEC-Q200
- Design_1: Radial
- Applications: DC/DC and AC/DC converter circuit in XEV, high-frequency and high-current circuits
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: Plastic foil capacitors
- Dielectric made of polypropylene (PPT) film, metalized
- Flame-retardant epoxy resin coating
- High security (with safety function)
- High humidity resistance (85°C, 85%, 500V DC, 1000h
- High temperature change resistance (-55...+85°C, 1000 cycles)
- Load test at high temperatures (125°C, 450V DC, 1000h)
- Complies with AEC-Q200
- Wire diameter 1.0 mm.
- Pitch_1:27.5 mm
- Capacity 1 µF
- Capacity_1: 1
- Unit of capacity: µF
- Capacity Tolerance 5%
- Dielectric: Metallized PP film
- Nominal voltage DC 630 V
- Insulation value in sec.: 3,000 sec.
- Product type
MKP thin film capacitor
- Type
Radial lead
- Dim
(L x W x H) 31.5 x 9.5 x 18.0 mm
- Capacity (elec.)
1 µF
- Nominal voltage
630 V
- Tolerance ±
5 %
- Height
18.0 mm
- Content
1 pc(s)
- Width
9.5 mm
- Length
31.5 mm
- RoHS-compliant
Yes
- Type
ECWFG2J105J
- Operating temperature (max.)
110 °C
- Operating temperature (min.)
-40 °C
- Certification marks
Complies with AEC-Q200
Documents & Downloads
Datasheet
Datasheet 3463475 Panasonic MKP thin film capacitor Radial lead 1 µF 630 V 5 % (L x W x H) 31.5 x 9.5 x 18.0 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463475 Panasonic MKP thin film capacitor Radial lead 1 µF 630 V 5 % (L x W x H) 31.5 x 9.5 x 18.0 mm 1 pc(s)
Description
Panasonic ECWFG MPP film capacitor
